HAGER'

HAGER RESERVES THE RIGHT TO MAKE DESIGN CHANGES WITHOUT NOTICE. CALL HAGER ENGINEERING MATERIAL AT 1-800-325-9995 FOR THE LATEST REVISION DATE OF TEMPLATE.

PRIMARY DIMENSIONS SHOWN IN INCHES, DIMENSIONS IN [] ARE MILLIMETERS.

DRAWN ENG. APPR. Material <not specified> TOLERANCES: FINISH FRACTIONAL: ±0.015" ANGULAR: MACH: ± 1° BEND: ±1° TWO PLACE DECIMAL: ±0.01" DO NOT SCALE DRAWING

MRJ

8/26/2008 380S SURFACE MOUNT

SIZE DWG. NO. REV. 02 Α T-TA00068 THREE PLACE DECIMAL: ±0.004" SCALE:1:4 WEIGHT: 0.99 SHEET 1 OF 1
