MRS-STP

Mortise Lock

STAND-ALONE SMART LOCK

Multi-Credential Options

EXTERIOR VIEW

ROUND ROSE (SJ)

SOUARE ROSE (SR) I-TRIM

Works With

Product Features

Access Types Smartphone, PIN access codes, smart remote, smartwatch, traditional key override

Access Levels 24/7 access, ability to create schedules. Two-factor authentication capable

Max Users 100 users maximum

Audit Trail 25 events stored locally in APP, 1 years' worth in the cloud. Defined # of events. Event filtering and

report exporting is standard

Notifications Supports 24 standard Push notifications

Managed locally (APP) or PIN codes via PIN pad Programmed

Power Source 4 AA alkaline batteries

Back set 2-3/4"

Door Thickness 1-3/4" standard, 2" and 2-1/4" options available

Handing Non-handed, field reversible

Operation Always locked or can be set to Passage mode.

Chassis Built on PDQ MR Grade 1 heavy-duty chassis, tested to over 11 million cycles (equivalent to operating

the lever every 60 seconds for 26.5 years without failure)

Cylinders Conventional, SFIC, Schlage LFIC, High Security and UL 437

22 keyways plus Restricted, High Security and UL 437

Keypad Capacitive touch, back lit

Certifications UL 20 min other ratings pending.

Environment Suitable for interior/exterior applications -31 to 150F weatherized

Retrofits Easy retrofits, utilizes standard mortise door prep

Remote Operation Requires the addition of an ethernet bridge

Upgradeable STP can be upgraded to networked access control with the addition of a Hybrid Cloud Network Device

Keying

Typical Applications

• Primary Residences
• Airbnb / Vacation Homes/ Vrbo
• Rental Properties
• Realtors
• Offices / Co-Working Spaces
• Small Business
• Retail
• Medical/ Dental Clinics
• Daycare/ Volunteer Centers
• Fitness Centers/ Gyms
• Warehouses / Distribution Facilities
• Manufacturing Companies
• K-12/ Higher Ed/ Private Schools
• Houses of Worship
• Airports and Transit Centers

Lever Styles Cylinders

PHILADELPHIA — PHL BOSTON — BSN MIAMI — MIA CHICAGO — CHI

DALLAS — DAL MEMPHIS — MEM ORLANDO — ORL LOS ANGELES — LA

Architectural Finishes

605 (US3) Bright Brass

606 (US4) Satin Brass

612 (US10) Satin Bronze

613 (US10B) Oil Rubbed Bronze

622 (US19) Flat Black

626 (US26D) Satin Chromium

629 (US32) Bright Stainless

Stand-Alone Smart Locking Solutions

Grade 1 Cylindrical GTS-STP

Heavy-Duty Deadbolt KMS-STP

Grade 2 Cylindrical SDS-STP

Grade 1 Mortise MRS-STP

Heavy-Duty Exit Device Trim 6EWS-STP

Standard-Duty Interconnected CLS-STP
