GTS-XLS

Grade 1 Cylindrical Lock

WIRELESS NETWORKED ACCESS CONTROL

Multi-Credential Options

Product Features

EXTERIOR VIEW

INTERIOR VIEW

Access Types

Access Levels Max Users

Audit Trail

Notifications

Programmed

Communication

Security

Power Source

Back set

Door Thickness

Handing

Operation

Chassis

Cylinders

Keying Keypad

Certifications

Environment Retrofits

Remote Operation

Upgradeable

Smartphone, PIN access codes, RFID, smart remote, smartwatch, traditional key override. Two-factor authentication capable

Administrator defined through the Cloud Based Access Control Interface

1000 users locally, Unlimited in the cloud

Real time events tracking through the app or Cloud Based Access Control Interface. Event filtering

and report exporting is standard

Email or SMS notifications, Administrator defined through the Cloud Based Access Control Interface

All user and credential data is added through the Cloud Based Access Control Interface

Hybrid BLE and ANT+ wireless mesh network

Patented End2End AES 128-bit with Cypher Block Chaining

4 AA alkaline batteries

2-3/4" standard, 5" as an option

1-3/4" - 2-1/4" thick, preset for 1-3/4"

Non-handed, field reversible

Always locked or can be set to Passage mode.

Built on PDQ GT Grade 1 heavy-duty chassis, abusive lever torque tested to over 2,000 in-lbs.

Over 2x BHMA Standard

Conventional, SFIC, Schlage LFIC, High Security and UL 437

22 keyways plus Restricted, High Security and UL 437

Capacitive touch, back lit. Integrated Mifare RFID reader

UL 20 min other ratings pending

Suitable for interior/exterior applications -31 to 150F weatherized

Easy retrofits, covers standard 161 door prep, requires additional holes

Remotely operated and controlled via our wireless mesh network

Over the Air Firmware ensures the products remain cyber secure and evolve capabilities over time

Typical Applications

• Multi-Family
• Assisted Living
• Hospitality
• Government Facilites
• Offices / Co-Working Spaces
• Public Buildings
• Retail
• Medical/ Dental Clinics
• K-12 / Higher Ed / Private Schools
• Industrial

• Warehouses / Distribution Facilities
• Manufacturing Companies
• Maintenance areas
• Houses of Worship
• Airports and Transit Centers

Lever Styles

PHILADELPHIA — PHL BOSTON — BSN MIAMI — MIA

Cylinders

Architectural Finishes

606 (US4) Satin Brass

612 (US10) Satin Bronze

613 (US10B) Oil Rubbed Bronze

622 (US19) Flat Black

626 (US26D) Satin Chromium

Wireless Networked Smart Locking Solutions

Grade 1 Cylindrical GTS-XLS

Heavy-Duty Deadbolt KMS-XLS

Grade 2 Cylindrical SDS-XLS

Grade 1 Mortise MRS-XLS

Heavy-Duty Exit Device Trim 6EWS-XLS

Standard-Duty Interconnected CLS-XLS*

*Contact factory for availability
