PRODUCT: X-10™ High Security Lock

SUBJECT: X-10 and X-09; Quick Reference Guide -

Feature Comparison

BULLETIN: #043

DATE: 08/05/2013

X-10 and X-09; Quick Reference Guide – Feature Comparison

The X-10 was developed as a result of the Government revision of Federal Specification FF-L-4720, now Rev. B. The X-10 was designed with similar features as the X-09 to minimize installation and user training issues. Like the X-09, the X-10 Dial Ring is Battleship Gray, with the same reduced view LCD. The dialing technique remains "Left-Right-Left". The X-10 has the same three operating modes and programming method. The Lock Case and Dial Ring mounting locations are the same. The X-10 has similar audit features. The X-10 is a Self Powered - Green Technology Product.

The following is a quick reference comparison of changes in product features:

Feature	X-09	X-10	Comment
Lock Case	Field Assembly	Through Case Mounting	Sealed Lock Case, Ease of Installation
Serial Number	Six-Digit	Eight-Digit	X-0 Series, One Million Sold
Lock Motor	Stepper Motor	DC Motor	New Lock Design
Lock Cable Orientation	6:00 3 Hrs. Behind Bolt	3:00 Opposite of Bolt	New Lock Design
Lock Bolt Options	Flush and Extended Four Options	One Bolt Flush - Tapped	Enhanced Design Fewer Parts
Product ID "Dial Ring"	Factory Location Mo. and Yr. Made	Product Identification Factory Location Mo. and Yr. Made	Product Differentiation
ID Stamp Location	9:00	8:00	Product Differentiation

Note: The above comparison is intended as a quick reference only. It is not intended as a listing of all product features.
