Severe Windstorm Resistant Components for Swinging Door Assemblies ANSI/SDI A250.13 - 2003 Standard
The following products have been approved for statewide acceptance by the Florida Building Commission pursuant to Rule 9B-72.090, F.A.C., for approval of products and systems for use on Exterior Swinging Door Assemblies, in compliance with the structural requirements of the 2010 Florida Building Code. Verification of Florida Statewide acceptance can be found at www.floridabuilding.org under the Product Approval section.
| Certified Hardware |
Assembly
Configuration |
Door Size |
Door
Stiffness Class |
Design Load |
Florida
Certification Number (FL#) |
|---|---|---|---|---|---|
|
3100 Series Gr. 1
Deadbolt |
Single - Out Swing | 3-0 x 7-0 | - | 1150 lbf (100 psf)* | 6118.1 |
| Single - Out Swing | 4-0 x 8-0 | - | 1150 lbf (70 psf)* | ||
|
3200 Series Gr. 2
Deadbolt |
Single - Out Swing | 3-0 x 7-0 | - | 1150 lbf (100 psf)* | 6118.2 |
| Single - Out Swing | 4-0 x 8-0 | - | 1150 lbf (70 psf)* | ||
|
3400 Series Gr. 1
Lockset |
Single - Out Swing | 3-0 x 7-0 | - | 1150 lbf (100 psf)* | 6118.3 |
| Single - Out Swing | 4-0 x 8-0 | - | 1150 lbf (70 psf)* | ||
|
3500 Series Gr. 2
Lockset |
Single - Out Swing | 3-0 x 7-0 | - | 860 lbf (80 psf)* | 7683.1 |
| Single - Out Swing | 4-0 x 8-0 | - | 860 lbf (50 psf)* | ||
| 3800 Series Gr. 1 | Single - Out Swing | 3-0 x 7-0 | - | 1150 lbf (100 psf)* | 12932.1 |
| Mortise w/Deadbolt | Single - Out Swing | 4-0 x 8-0 | - | 1150 lbf (70 psf)* | |
| 4500 Rim Exit Device | Single - Out Swing | 4-0 x 8-0 max. | I |
+/- 70 psf
350 ft-lbs Impact |
9481.1 |
| 4500 SVR Exit Device | Out Swing | 8-0 x 8-0 pair max. | I |
+/- 50 psf
350 ft-lbs Impact |
13178.1 |
| 4700 Rim Exit Device | Single - Out Swing | 4-0 x 8-0 max. | I |
+/- 40 psf
350 ft-lbs Impact |
8293.1 |
| 780-112 Roton Hinge | Single Swing | 4-0 x 8-0 max. | I |
1150 lbf (72 psf)*
350 ft-lbs Impact |
6118.4 |
| 780-111 SD & HD | Single Swing | 4-0 x 8-0 max. | I |
1150 lbf (72 psf)*
350 ft-lbs Impact |
13776.3 |
| 780-224 SD &HD | 13776.5 | ||||
| 780-226 SD & HD | 13776.6 | ||||
| BB1191 Hinge | Single - Out Swing | - | - | 1780 lbf** | 6118.5 |
| 1191 Butt Hinge | Single - Out Swing | - | - | 1780 lbf** | 13776.1 |
| 1279 Butt Hinge | 13776.2 | ||||
| BB1279 Butt Hinge | 13776.9 | ||||
| BB1168 Butt Hinge | 13776.7 | ||||
| BB1199 But Hinge | 13776.8 |
* Load in parenthesis indicates the equivalent load in pounds per square foot based on indicated door size and door stiffness (if applicable). This load is based on the hardware item taking half of the force applied to the door assembly by the wind load and the hinges taking the other half.
** This load indicates the design load for a single butt hinge. Maximum wind load should be calculated based on door size, number of hinges used, and the other available door hardware on the door assembly.
