Corbin Russwin Top and Bottom Strikes for MP9800 Series Multi-Point Locks H.M. and Wood Doors Template

Original Source Document Full PDF Version

Corbin Russwin Top and Bottom Strikes for MP9800 Series Multi-Point Locks H.M. and Wood Doors Template_T31241 diagram on page

Corbin Russwin Top and Bottom Strikes for MP9800 Series Multi-Point Locks H.M. and Wood Doors Template_T31241 image on page 1

1.If device backset is 1-5/8" (41) or more than strike is centered on bolt.
2.If device backset is less than 1-5/8" (41) to 1-1/8" (28.5) than strike is centered at 1-3/8" (35) backset.
3.If device backset is less than 1-1/8" (28.5) this strike can not be used. Consult factory for alternate strike.

Corbin Russwin Top and Bottom Strikes for MP9800 Series Multi-Point Locks H.M. and Wood Doors Template_T31241 image on page 1

this dimension accordingly.

NOTES:

1. Do not scale.
2. Dimensions given in inches (mm).
3. Outside dimensions are maximum part size.
4. Minimum backset depends on device and application. See device template for minimum backset.

RESPONSIBILITY

DOOR AND FRAME MANUFACTURERS ARE RESPONSIBLE FOR PROVIDING ADEQUATE CONSTRUCTION OR REINFORCEMENTS FOR PROPER INSTALLATION OF HARDWARE SHOWN. ALL ARCHITECTURAL BUILDERS HARDWARE MUST BE INSTALLED ON PROPERLY REINFORCED DOORS AND FRAMES, REGARDLESS OF TYPE, MATERIAL, OR METHOD OF CONSTRUCTION.

MP9800 Series Multi-Point Locks Top & Bottom Strike Hollow Metal & Wood Doors

Corbin Russwin Top and Bottom Strikes for MP9800 Series Multi-Point Locks H.M. and Wood Doors Template_T31241 diagram on page
