OUTSIDE FACE OF DOOR Section X - X X 1/2 (13) Dia. Thru Door (5 Places) 1-3/8 (35) 3-5/8 (92) Vertical Reference (Trim Centerline) 3-5/8 (92) X 11/16 (17.5) 9-15/16 (252) 2-1/16 (52) CL CL 1-1/2 (38) Dia. 1-3/8 (35) Deep Notes: 1. This template is an addition to the device template. Locate centerlines using horizontal and vertical references on device template. 2. Do not scale drawing. 3. Dimensions are in inches (mm). 4. LHR door shown. Preparation is typical for both door hands. 5. Provide adequate structural support to maintain door integrity during operation. 6. Prepare mounting holes when installing trim. 7. Shaded areas represents mortise lock cavity from device template. Horizontal Reference (Device Centerline) Inside Face Of Door 7/8 (22) 3/8 (9.5) Dia. 3/4 (19) Deep TH9M57

TH9M57 Trim Wood or Composite Door Preparation With ED5600 Series Mortise Exit Devices
