OUTSIDE FACE OF DOOR 3-5/8 X CL Notes: 1. This template is an addition to the device template. Locate centerlines using horizontal and vertical references on device template. 2. Do not scale drawing. 3. Dimensions are in inches (mm). 4. LHR door shown. Preparation is typical for both door hands. 5. For door reinforcement see template T30800. 6. Prepare mounting holes when installing trim. 7. Provide adequate internal support to prevent door deformation from bolting trim to the device. 8. Unspecified radii 1/8 (3) maximum. Outside Face Vertical Reference (Trim Centerline) Inside Face Of Door 1-1/2 Dia. (38) TH9M55

TH9M55 Trim Metal Door Preparation With ED5600 Series Mortise Exit Devices

DO NOT SCALE DRAWING SUPERSEDES TEMPLATE NUMBER DATE T31018 6-06
