OUTSIDE FACE OF DOOR Section X - X X 1-3/8 (35) 3-5/8 (92) 3-5/8 (92) X 9-15/16 (252) Horizontal Reference (Device Centerline) CL CL 11/16 (17.5) Notes: 1. This template is an addition to the device template. Locate centerlines using horizontal and vertical references on device template. 2. Do not scale drawing. 3. Dimensions are in inches (mm). 4. LHR door shown. Preparation is typical for both door hands. 5. Shaded area represents mortise lock cavity from device template. 6. Prepare mounting holes when installing trim. 7. Provide adequate structural support to maintain door integrity during operation. 8. Unspecified radii 1/8 (3) maximum. Vertical Reference (Trim Centerline) Inside Face Of Door ® 1/2 (13) Dia. Thru Door (5 Places) 7/8 (22) 3/8 (9.5) Dia. 3/4 (19) Deep TH9 10 M 1/8 (3) 1/4 (6) Radius 2" (51) 3/4 (19) Cutout 1-3/8 (35) Deep 3/4 (19) Radius (Typical)

TH9M10 Trim Wood or Composite Door Preparation With ED5600 Series Mortise Exit Devices

DO NOT SCALE DRAWING SUPERSEDES

TEMPLATE NUMBER DATE

T31017 6-06
