OUTSIDE FACE OF DOOR X 1-3/8 (35) 3-5/8 (92) 3-5/8 (92) X CL 11/16 (17.5) 9-15/16 (252) CL CL 1/4 (6) 1/2 (13) Dia. Notes: 1. This template is an addition to the device template. Locate centerlines using horizontal and vertical references on device template. 2. Do not scale drawing. 3. Dimensions are in inches (mm). 4. LHR door shown. Preparation is typical for both door hands. 5. Provide adequate internal support to maintain door integrity during operation. 6. Prepare mounting holes when installing trim. 7. Dimensions given about a centerline are symmetrical. Horizontal Reference (Device Centerline) Vertical Reference (Trim Centerline) Inside Face of Door 1/2 (13) Dia. Thru Door (5 Places) 7/8 (22) 3/8 (9.5) Dia. TH957 1-1/2 (38) Dia 1-1/4 (32) Deep

3/4 (19) Deep

TH957 Trim Wood or Composite Door Preparation with ED5200, ED5400, or ED5800 Series Rim and Vertical Rod Exit Devices

Section X - X
