Installation Instructions

MP9800 Series Multi-Point Lock Auxiliary Control

Corbin Russwin MP9800 Series Multi-Point Locks with Auxiliary Control Installation Instructions_FM439 image on page 1

Corbin Russwin MP9800 Series Multi-Point Locks with Auxiliary Control Installation Instructions_FM439 diagram on page 1

Corbin Russwin MP9800 Series Multi-Point Locks with Auxiliary Control Installation Instructions_FM439 diagram on page 1

  • 1. PREPARE DOOR USING APPROPRIATE MP9800 SERIES INSTRUCTIONS.
  • 2. PREPARE DOOR FOR AUXILIARY CONTROL AS ILLUSTRATED ABOVE.
  • 3. MOUNT MP9800 SERIES TO DOOR FOLLOWING APPROPRIATE INSTRUCTIONS.
  • 4. MOUNT AUXILIARY CONTROL TO DOOR AS ILLUSTRATED ABOVE.

THE STOREROOM (AUX159) AUXILIARY CONTROL IS OPERATIVE ONLY WHEN THE KEY IS IN THE CYLINDER AND TURNED.

THE CLASSROOM (AUX155) AUXILIARY CONTROL CAN BE MADE OPERATIVE OR INOPERATIVE BY TURNING THE KEY.

MP9800 Series Multi-Point Lock Auxiliary Control
