FE6800 Series
Multi-Point Lock
Why is Corbin Russwin offering the FE6800 Series again?
This product is for facilities that currently have a SARGENT FM7100 Series or Corbin Russwin FE6800 Series multi-point lock installed but needs to be replaced.
What codes does the FE6800 Series meet?
The FE6800 Series meets the following certifications: ICC500, ANSI/BHMA A156.37 Grade 1, FEMA P-320, FEMA P-361, and 3 hour UL-10C fire listing.
What functions are available?
The FE6800 Series is available with 3 functions: Classroom, Passage or Closet and Only Passage.
Are there any electrified monitoring options, available with the FE6800 Series?
No. Consider upgrading to our newer version the FE6800 Series which has numerous opt available.
Can you use access control with this product?
No. Consider upgrading to our newer version, the FE6800 Series which is compatible with multiple access control products
Is there a hold-back feature with the FE6600 Series?
No. Consider upgrading to our newer version, the FE6800 Series which has this feature.
Are there indicator options available in the FE6800 Series?
No. Consider upgrading to our newer version, the FE6600 Series which has this available.
What doors work with the FE6800 Series?
The FE6800 Series must be installed on StormPro® 361 tornado resistant assemblies from Ceco Door and Curries. McKinney StormPro® Hinges must also be used.
What size and swings have been approved?
The FE6800 Series is approved for installation on in-swing or out-swing single or pairs of doors. Doors sizes measure 4'0" x 8'0" on single doors and 8'0" x 8'0" pairs of doors.
What accessories will work with the FE6800 Series and comply with the necessary codes?
- Door Closers: Corbin Russwin 281 Se Corbin Russwin DC8000 Series, Norton Series, and Yale 4400 Series
- Surface Bolts: Corbin Russwin 988
- Accessories: Pemko S773 adhesive applied gasketing; Pemko 346 rain drip guar Pemko 345 door bottom sweep; Pemko 2715 threshold; Pemko 305 astragal seal; Securitron CEPT Power Transfer: Securitron DPS-M door position switch
- Hinges: McKinney StormPro® hinges
Does the FE6800 Series require a factory trained installer?
Corbin Russwin recommends that the FE6800 eries be installed by a factory trained installer. Factory training is available through ASSA ABLOY mericas University.
What is the warranty for the FE6800 Series?
The FE6800 Series is covered by a 7 year warranty.
Can you install the FE6800 Series in new openings?
No, the FE6800 Series is for retrofit applications only.
Can I reuse my existing FE6800 Series hardware if I am replacing my door?
Yes. If your hardware is still under warranty, a factory trained installer is recommended to install the new door with the existing hardware. If your hardware is no longer under warranty, it is recommended to use a factory trained installer to extend the life of the product.
How do I order the FE6800 Series?
Orders for this product are handled as a special order. Please contact your local ASSA ABLOY Door Security Solutions sales representative to order.
