• DIMENSIONS GIVEN IN INCHES AND (MM).

RESPONSIBILITY

Door and Frame Manufacturers are responsible for providing adequate construction or reinforcements for proper installation of hardware shown. All architectural builders hardware must be installed on properly reinforced doors and frames, regardless of the type,

material, or method of construction.

ED6200 BY ED6400 SERIES BY SO2 STRIKE

CROSSBAR RIM BY VERTICAL ROD DEVICES

TEMPLATE CROSS REFERENCE

DO NOT SCALE DRAWING SUPERSEDES

WT30105 BTH

03/29/93 NUMBER
