Installation Instructions

DL4100 Series Auxiliary Deadlock FM 338 10/18

/ WARNING

This product can expose you to lead which is known to the state of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65warnings.ca.gov

In U.S.: Corbin Russwin, Inc. 225 Episcopal Road

ASSA ABLOY In Canada: ASSA ABI OY Door Security Solutions Canada 160 Four Valley Drive Vaughan, Ontario, Canada L4K 4T9

Phone: 800-461-3007

Technical Product Support: Phone: 888-607-5703

Berlin, CT 06037 USA Phone: 800-543-3658

EXAMINE LOCKSET TO MAKE SURE IT IS THE CORRECT BEVEL FOR DOOR. IF NOT, LOOSEN SCREWS (FASTENING FRONT TO CASE). ROTATE FRONT TO PROPER BEVEL & RETIGHTEN SCREWS
