MOUNTING INFORMATION

Sex nuts or through balts are required for wood and plastic covered composite doors, and any type of door without reinforcements and recommended for wood core and metal clad (Kalamein) type doors.

RH SHOWN LH OPPOSITE

TEMPLATE CROSS R	EFERENCE
DESCRIPTION	TEMPLATE
DC26910 SERIES	T30536
DC26920 SERIES	T30534
DC26930 SERIES	T30537

CAUTION : CLOSER TO BE INSTALLED IN A TRUE HORIZONTAL POSITION TO ENSURE PROPER CLOSER PERFORMANCE.

RESPONSIBILITY

Door and Frame Manufacturers are

responsible for providing adequate construction or reinforcements for proper installation of hardware shown. All architectural builders hardware must be installed on properly reinforced doors and frames, regardless of the type, material, or method of construction.

DC26900 SERIES

ELECTROMECHANICAL SURFACE DOOR CLOSER REGULAR MOUNTING

Corbin Z

SUPERSEDES V T 3 0 0 2 8 PR. KJ
