MOUNTING INFORMATION

Sex nuts or through bolts are required for wood and plastic covered composite doors, and any type of door without reinforcements and recommended for wood core and metal clad (Kalamein) tupe doors.

RH SHOWN LH OPPOSITE

TEMPLATE CROSS REFERENCE OESCRIPTION TEMPLATE OC26910 x M82 T30522

CAUTION: CLOSER TO BE INSTALLED IN A TRUE HORIZONTAL POSITION TO ENSURE PROPER CLOSER PERFORMANCE.

RESPONSIBILITY

Door and Frame Manufacturers are responsible for providing adequate construction or reinforcements for proper installation of hardware shown. All architectural builders hardware must be installed on properly reinforced doors and frames, regardless of the type, material, or method of construction.

DC26910 SERIES

ELECTROMECHANICAL SURFACE DOOR CLOSER PARALLEL ARM MOUNTING

Corbin Z

SUPERSEDES VT30191 DR. KJ PLANE
