Corbin Russwin ASSA ABLOY
PoE Campus Access Control
Specifications and System Requirements
Credential Support:
- › Magstripe
- › 2.4 GHz credentials:
- Secure Identity Object™ (SIO) on Mobile IDs (Bluetooth Smart)
- › 13.56 MHz credentials:
- iCLASS®
- iCLASS SE® (SIO-enabled)
- iCLASS® Seos®
- SIO on MIFARE® Classic
- SIO on MIFARE DESFire® EV1
- MIFARE Classic
- MIFARE DESFire EV1
- NFC-enabled mobile phones
-
› 125 kHz credentials:
- HID Prox®
Technical Specifications:
› Conforms to IEEE 802.3af Class 1 standard, requiring less than 3.84 watts
Software:
› Compatible with the ASSA ABLOY PERSONA Campus™ software or with an approved third party access control software
Security:
› AES 128-bit encryption
EAC Regulatory Compliance*:
- › UL294 6th Edition
- › CAN/ULC S319
- › BHMA A156.25
- * Excludes multi-point locks
Available through Authorized Channel Partners only. Contact your ASSA ABLOY Door Security Solutions sales consultant for details.
For more information or a personal demonstration, contact PERSONA at 1-800-481-8464 or visit www.intelligentopenings.com
PoE Campus Access Control
| Features | Benefits |
|
Utilizes IEEE 802.3af PoE-enabled network
infrastructure for both power and data |
• Streamlines the installation process, reducing costs
• Eliminates the need for any proprietary equipment |
|
HID® multiCLASS SE® Technology with
magnetic stripe reader |
• Enables real-time communication
• Provides heightened security • Supports: – Multiple credential technologies, offering easy migration from magnetic stripe or other contactless cards to higher security credentials or consolidation of mixed credentials – HID Mobile Access® powered by Seos®, for both iOS® and Android™ devices |
| Keypad option available | • Two-factor authentication offers enhanced security |
|
Intelligence built into lock for local
decision making |
• Lock operates regardless of network status
• Supports up to 2,400/10,000 users* • Provides a 10,000 event transaction history/audit trail |
| Privacy button |
• Allows shelter in place/local lockdown
• Enables privacy capabilities for applications such as residence halls |
|
Reduced energy consumption and product
sustainability measures |
• Uses up to 76% less power in standby mode than traditional
access control installations, as certified by GreenCircle • Reuses existing network infrastructure • Streamlined system architecture provides improved reliability and reduces materials |
|
Integrated ANSI/BHMA Grade 1 hardware,
available in cylindrical lock, mortise lock, multi point lock, and exit device configurations |
• Flexibility to support various openings
• Assurance of high quality hardware |
|
Available with a wide range of finishes and
decorative levers |
• Blends into any environment seamlessly
• Designed to meet the requirements of designers and architects |
| * Contact your access control system manufacturer for more information |
* Contact your access control system manufacturer for more information
