WiFi Campus Access Control
Specifications and System Requirements
Credential Support:
- › Magstripe
- › 2.4 GHz credentials:
- Secure Identity Object™ (SIO) on Mobile IDs (Bluetooth Smart)
- › 13.56 MHz credentials:
- iCLASS®
- iCLASS SE® (SIO-enabled)
- iCLASS® Seos®
- SIO on MIFARE® Classic
- SIO on MIFARE DESFire® EV1
- MIFARE Classic
- MIFARE DESFire EV1
- NFC-enabled mobile phones
-
› 125 kHz credentials:
- HID Prox®
Operating Power:
› 9VDC (6 AA) batteries
Software:
› Compatible with approved third party access control software
Security:
- › AES 128-bit encryption
- › Supports current WiFi network security standards, including:
- WEP, WPA and WPA2
- 802.1x
EAC Regulatory Compliance*:
- › UL294 6th Edition
- › CAN/ULC S319
- › BHMA A156.25
- * Excludes multi-point locks
Available through Authorized Channel Partners only. Contact your ASSA ABLOY Door Security Solutions sales consultant for details.
For more information or a personal demonstration, contact PERSONA at 1-800-481-8464 or visit www.intelligentopenings.com
WiFi Campus Access Control
| Features | Benefits |
|---|---|
| Utilizes IEEE 802.11 WiFi infrastructure |
• Significantly reduces installation costs
• Eliminates the need for any proprietary equipment • Ideal for hard-to-wire locations |
|
HID® multiCLASS SE® Technology with
magnetic stripe reader |
• Provides heightened security
• Supports: – Multiple credential technologies, offering easy migration from magnetic stripe or other contactless cards to higher security credentials or consolidation of mixed credentials – HID Mobile Access® powered by Seos®, for both iOS® and Android™ devices |
|
Keypad option available
Field-upgradable 802.11b/g/n radio |
• Two-factor authentication offers enhanced security
• Interoperability with other WiFi equipment • Future proof for constantly evolving WiFi standards |
|
Intelligence built into lock for local
decision making |
• Lock operates regardless of network status
• Supports up to 2,400/10,000 users* • Provides a 10,000 event transaction history/audit trail |
| Privacy button |
• Allows shelter in place/local lockdown
• Enables privacy capabilities for applications such as residence halls |
| Field selectable communication frequency |
• Allows you to balance security requirements with
battery life |
|
Integrated ANSI/BHMA Grade 1 hardware,
available in cylindrical lock, mortise lock, multi point lock, and exit device configurations |
• Flexibility to support various openings
• Assurance of high quality hardware |
|
Available with a wide range of finishes and
decorative levers |
• Blends into any environment seamlessly
• Designed to meet the requirements of designers and architects |
* Contact your access control system manufacturer for more information
Typical System Configuration
802.11 b/g/n Wireless Access Point
