Z7700 Series Mortise Locks Pricelist
Open the original PDF document
View PDFMLR Locksets incorporate an SDC manufactured Grade 1 Heavy Duty mortise lockset and vandal resistant clutch mechanism. All operational attributes are field selectable. 620 mA inrush, 160 mA holding @ 24VDC (motor), 300 mA @ 24VDC (solenoid). Patent Pending
FIELD SELECTABLE ATTRIBUTES
- Selectable function, locked outside only or both sides
- Selectable handing
Electrically Controlled Single Point Locks or Latches 3 Hr A Label Fire Rated Doors
07F
GE
EE
SPECIFY FUNCTION AND MODE LIST SDC Supplied Electrified Lock (Mortise cylinder not included). SDC Brand lockset. Clutch for lever trim vandal resistance. * Less trim - compatible with Schlage trim With SDC Trim * Less Trim 861.00 1,242.00 Z7730 Locked both sides, failsafe Z7732 Locked both sides, failsecure 861.00 1,242.00 Z7750 Locked outside only, failsafe 861.00 1,242.00 Z7752 861.00 Locked outside only, failsecure 1,242.00
| S | PECIFY HAND | • | |||||||
|---|---|---|---|---|---|---|---|---|---|
| L | Left hand | LR | Left hand reversed | All han | ds are fi | eld rev | versible | e I | N/C |
| R | Right hand | RR | Right hand reversed | I | N/C |
Optional Outputs
| R | Request-to-exit. Indicates inside lever operation for access control request-to-exit input, alarm shunt, remote annunciation or CCTV activation, N.O. SPST 1 Amp @ 30VDC | 89.00 |
|---|---|---|
| D | Door position status output. (MC-4 Door Contact) | 54.00 |
| L | Latchbolt Status SPDT 1 Amp @ 30VDC | 89.00 |
| S | PECIFY LEVER TRIM | Add to List | |||
|---|---|---|---|---|---|
| G | Galaxy with rose | N/C | GI | Galaxy with escutched | on 112.00 |
| Ε | Eclipse with rose | N/C | EE | Eclipse with escutche | on 112.00 |
| N | Nova with rose | N/C | NE | Nova with escutcheor | 112.00 |
| 07 | 'Schlage equal with SDC B rose | N/C | 07 | E Schlage equal with SD | C escutcheon 112.00 |
Single Trim Option (add to List)
STM Single side trim mount adapter (only works with rose trim) 156.00
| ACCESSO | RIES | Add to List |
|---|---|---|
| Optional Cab | e and Connectors (for Z7700 Series ONLY) | |
| CC1-5-90 | 5ft. Cable and connectors for locks without optional outputs | 50.00 |
| CC3-5-90 | 5ft. Cable and connectors for locks with optional outputs | 67.00 |
| Р | IH |
|---|---|
| UL 10B Li | sted for 3Hr |
| Fire Rat | ed Doors |
| Optional Key Cylinder | s 1 required for 7750/7752 2 required for 7730/7732 | 49.00 |
|---|---|---|
| CYL-6KDQ 6 pin, | , 1.125" keyed different, 626 Dull Chrome | 49.00 |
| CYL-6KAQ 6 pin, | , 1.125" keyed alike, 626 Dull Chrome | 44.00 |
Power Transfer Hinge
UL listed, 4.5" x 4.5", five knuckle hinge.
| PTH-10Q | Ten wire, dull chrome | 217.00 |
|---|---|---|
| PTH-2+40 | 6-wire Flectric Hinge 1-pair 16 Amp inrush 4 Amp continuous:2-pair 1 Amp @ 12/24V | 195.00 |
