Yale Sectional Mortise Sell Sheet

Technical Specifications

Door Specifications: Fits into the standard mortise door prep

Backset: 2-3/4" (70mm) standard backset

Door Thickness: 1-3/4" (44mm) door thickness standard; please

specify for other door thicknesses

Handing: Field reversible

Latchbolt: 3/4" spring latchbolt standard, 1" throw deadlocking

latchbolt optional

Strike: Curved lip strike with 1-1/4" (32 mm) lip length standard

Cylinder: Accepts conventional, interchangeable core, security and high

security cylinders, and other manufacturers' keyway cylinders

ANSI/BHMA: Certified ANSI/BHMA Grade 1

UL/cUL: Functions are UL - cUL Fire Listed for use on fire doors having a rating up to

and including 3-hours

Warranty: 1-year electrical warranty; 3-year mechanical and finish warranty

Environmental Specifications: Operating temperature: -40°F to +140°F (-40°C to

+60°C) at 95% relative humidity when used with an external power supply

Power Source: 4 AA alkaline batteries (included) with optional hardwire input f or

9VDC external power; 9V battery power backup on keypad

Interface: Capacitive touchscreen or pushbutton keypad

User Codes: Up to 500 unique user codes

FInishes

ANSI/BHMA Code		Finish Description
605 (US3)		Bright Brass, Clear Coated
613E (US10BE)		Dark Oxidized Satin Bronze - equivalent
626 (US26D)		Satin Chrome Plated
BSP		Black Suede Powder Coat

arcadia arr

augusta auR

carmel crr

Jefferson JNR

Monroe Mor

pacific beach pbr

pinehurst pnr

virginia vnr

Contact your local ASSA ABLOY Door Security Solutions team or visit www.yalelocks.com
