TRANSFORMERS & PLUG-IN DC POWER SUPPLIES

TRANSFORMERS

POWER SUPPLIES

TR12

Plug-in DC Power supply with 2 secondary outputs.

• Primary: 120VAC, Grounded
• 1 Fused, Unregulated Lock Output: 12VDC @ 780 mA
• 1 Regulated Access Control Output: 12VDC @ 150 mA
• Screw Terminals

TJ2440

J-Box or Base Mounted Transformer

• Primary: 120VAC (wire leads)
• Secondary: 24VAC @ 1.65Amps (screw terminals)
• UL Listed, Class 2

Plug-In DC Supply

• Primary: 120VAC, grounded
• Secondary: Fused, unregulated 24VDC @ 1Amp
• 6 Ft. Cord

TB2450

Base Mounted Transformer

• Primary: 120VAC/240VAC (screw terminals)
• Secondary: 24VAC @ 2Amps (screw terminals)
• Field replaceable fuse
• UL Listed

TP1220

Plug-In Transformer

• Primary: 120VAC
• Secondary: fused, 12VAC @ 1.65Amps (screw terminals)
• UL Listed, Class 2

TB24100

Base Mounted Transformer

• Primary: 120VAC/240VAC (screw terminals)
• Secondary: 24VAC @ 4Amps (screw terminals)
• Field replaceable fuse
• UL Listed

TP2440

Plug-In Transformer

• Primary: 120VAC
• Secondary: fused, 24VAC @ 1.65Amps (screw terminals)
• UL Listed, Class 2

BR64XL

Full Wave Bridge Rectifier

• Input: 12 or 24VAC
• Output: 12 or 24VDC
• 4 Amps Maximum Load
