THRESHOLD BOLT KIT • HEADER BOLT SETS • HEADER SIGN

HARDWARE

TB-4015 THRESHOLD BOLT KIT

For doors with cylinder height up to 53-1/2". Threaded rod can be cut for cylinder heights lower than 53-1/2"

• Bolt 3/8" hexagon hardened steel
• 11/16" bolt throw
• Unit complete for attachment to basic Deadlock to provide two-point security

Specify: Model Number

For doors with cylinder height 34" to 37"

• Bolt 3/8" hexagon hardened steel
• 11/16" bolt throw
• Unit complete for attachment to basic Deadlock to provide two-point security

Specify: Model Number

HB-4015-N SPECIAL HEADER BOLT SET

HB-4015-N Header Bolt Set is Standard for 83" Doors with Cylinder Heights of not less than 33"

ER-4015-N Extension Rod Kit is Available for 8'-9' Door Heights

HB-4085 HEADER BOLT SET

For doors 30-1/2" to 50" from Centerline of cylinder to top of door

HB-4086 HEADER BOLT SET

For doors 55.5/8" 72-1/2" from Centerline of cylinder to top of door

HB-4087 HEADER BOLT SET

For doors 67" to 89" from Centerline of cylinder to top of door

• Inactive leaf lock when used with basic long Throw Deadlock in active leaf
• 5/8" throw expanding bolt
• Minor adjustments can be made after installation
• Unit complete with Rod Guide and Header Strike

Specify: Model Number

HS-4089 HEADER SIGN HS-4090 HEADER SIGN

• For use on transoms and door headers
• One piece self-adhesive decals
• Black letters on aluminum background

Specify: Model Number
