Stainless Steel Continuous Pin & Barrel Hinges

Non - Electrical Options

"CUT" - Cut to Custom Length

If a non-standard length hinge is required, ABH will cut from the bottom of the hinge to the desired length as long as it does not interfere with a screw hole. Specify length and handing .

"SPLICE" – Spliced Hinge

For hinges exceeding 118-¾", ABH splices two separate lengths with an alternately split stainless steel pin that holds the barrel together. Specify length and handing .

"HT" – Welded Hospital Tip

Top of the hinge barrel is cut at a 45° angle and then welded to help provide and support a safer environment in hospitals and other institutions. Specify handing .

"DD" – Dutch Door

Go online for order form or, specify top and bottom door leaf heights as well as clearance required between top and bottom and handing when ordering.

"STUD" – Security Studs

½" diameter stainless steel studs are permanantly mounted to the frame leaf projecting ¼" and extend into the door leaf for added security.

"AS" – Adjustable Studs

Threaded studs are supplied for hinges with door edge guards on both faces of the door to help correct door alignment issues up to ⅜". Additional door reinforcement required. Specify wood or metal door.

"SEC" – Security Fasteners

Security fasteners are supplied in lieu of standard fasteners for all exposed areas. Specify wood or metal door and frame

"SNB" – Sex Bolts

When using on wood doors, sex bolts are provided for the surface mounted door portion.

"LL" – Lead-Lined

Lead is provided for the door portion fastener cover for half surface and full surface hinges.

"SL" – Sheared Leaf

Concealed leaf is sheared to accommodate a 1-⅜" thick door.

"ADB" – Cut for Automatic Door Bottom

Specify automatic door bottom model when ordering.

"CUSTOM HOLE"

Contact factory with custom mounting hole locations desired for unusual frame and/or door conditions. Restrictions apply.

"NO HOLE"

Contact factory for hinge without mounting holes.

"CUSTOM FINISH"

factory for details. Customer color sample approval will be required prior to fabrication.

	A5500WT
