Size Options
|
Hinge Size
(inches) |
Hinge Size
(mm) |
Gauge of Metal | Hole Count |
Screw Size
(Machine) |
Screw Size
(Wood) |
|---|---|---|---|---|---|
| 4-1/2 x 4 | 114 x 102 | 0.134 | 8 | 1/2 x 12-24 | 1-1/4 x 12 |
| 4-1/2 x 4-1/2 | 114 x 114 | 0.134 | 8 | 1/2 x 12-24 | 1-1/4 x 12 |
