AQD5 Series 12/24 Power Supply/Charger 12VDC @ 5 Amps / 24VDC @ 3 Amps Life Time Warranty

  • Small Light Efficient Clean Power AQD5-8F
  • Universal AC Input 90-250vac
  • 12vdc 5A/24vdc 3A Switch Selectable
  • Smooth Linear Output Performance
  • Input and Output Surge Protection
  • Precise Battery Regulation for Wet, AGM, and sealed Lead Acid Battery(s)
  • Power Limited Output with Thermal Protection
  • Reverse Battery Protection
  • AC , Trouble, and DC LED's
  • Battery Online, No Drop or Switch Over with AC Power Fail
  • Quality Manufactured in the USA
  • UL Listed Access Control & Burglar Alarm systems
  • Relay "C" Contacts Indicates AC Power Status
  • Relay "C" Contacts Indicates Low Battery Amber LED Indicates Power Normal
  • Battery Cut-Off Relay Disconnects Battery(s) when Depleted
  • DC Output is Class II Power Limited Ordering examples:

AQD5 Supervised Power Supply/Charger module with
a 14"x8.5"x3.5" Enclosure
-4F AQD5 with one PDB-4F
-4C AQD5 with one PDB-4C
-8F AQD5 with one PDM-8-075-200
-8C AQD5 with one PDM-8-075-090
-1R AQD5 with one PDB-FT
-8C1R AQD5 with one PDB-8C1R
-8F8R AQD5 with one PDB-8F8R (Not UL Listed)

Description / Instructions

The AQD5 are heavy duty self contained, efficient, clean, linear performance off-line switching power supplies that are slide switch selectable between 12vdc at 5 Amps, and 24vdc at 3 Amps. Both have a precision lead acid battery(s) charger that obtains maximum battery life while providing a 12vdc or 24vdc uninterruptible power supply for access control security systems. The universal AC input allows these power supplies to be powered anywhere in the world without any alteration. The AQD5 has exceptional brown out capability with operation down to 60vac. The AQD5 has an extensive filtering system that provides linear output performance. The AQD5 is electronically protected against Battery(s) reversal, shorting or

overloading. The DC output is power limited, and thermally protected. Each of these protective features will self-restore. Before connecting load and battery(s), slide 12v/24v selector switch to desired voltage. Caution , damage can occur when switched with DC output load. Confirm proper voltage before connecting devices. The AQD5 is UL Listed and has the additional supervisory features of a Battery disconnect relay when battery(s) are depleted, a set of form "C" relay contacts that indicates AC power failure, a set of form "C" relay contacts to indicate low battery(s) and the DC Output is Class II power limited. Depending on load, low battery trouble indicates 50-75% battery capacity remaining. Because the output of the AQD5 is Class II Power
