Securakey Wiegand Card and Numbering Schematic Data Sheet
Open the original PDF document
View PDF
| WIEGAND SWIPE CARDS: PART NUMBERING SCHEME | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Technology | Config. | Style | Artwork* | Numbering |
Number
Loc. |
Finish | Mag Stripe | Slot | |
|
WC- Wiegand
+ no inlay |
CI-
Card |
10
(30 mil) |
C-custom |
M-match
internal |
F-Front |
GA-
gloss all |
B-on back | P-portrait | |
|
WE - Wiegand
+ LF OR HF |
CS-
Code Strip |
11
(37 mil) |
S-secura key logos | N-nonmatching | B-Back |
MA-
matte all |
F-on front | L-landscape | |
|
14
47 mil (tuffcard) |
N-none
(blank) |
F-match
internal w/facility code |
GF-
gloss front |
N-no stripe | N-no slot | ||||
|
16
47 mil (prox+wieg) |
GB-
gloss back |
||||||||
|
20**
37 mil (HF+ wieg) |
|||||||||
Example Part Number: WCCI-11-NMBGANL = Wiegand Card, 37 mil thick, no artwork, laser numbering matches internal code, number on back, glossy both sides, no magstripe, landscape slot.
NOTE: Secura Key does not offer "zero-gap" Wiegand card encoding; if gaps in number sequence occur due to production fallout, additional cards will be supplied to fulfill the quantity ordered.
| WIEGAND SWIPE CARDS: HID® VS SECURA KEY PART NUMBER EQUIVALENCY | ||||||
|---|---|---|---|---|---|---|
| HID* | Description | Secura Key** | ||||
| 100nnnn | 30 mil Wiegand card, matte finish | WCCI10-NMBMANN | ||||
| 109nnnn | 30 mil Wiegand card, glossy finish | WCCI10-NMBGANN | ||||
| 110nnnn | 37 mil Wiegand card, matte finish | WCCI11-NMBMANN | ||||
| 119nnnn | 37 mil Wiegand card, glossy finish | WCCI11-NMBGANN | ||||
| 140nnnn | 47 mil Wiegand card, matte finish, extra thick "tuffcard" | WCCI14-NMBMANN | ||||
| 149nnnn | 47 mil Wiegand card, glossy finish, extra thick "tuffcard" | WCCI14-NMBGANN | ||||
| 160nnnn | 47 mil Wiegand + proximity card, matte finish | WECI16-NMBMANN | ||||
| 169nnnn | 47 mil Wiegand + proximity card, matte finish | WECI16-NMBGANN | ||||
* In the HID part numbering, nnnn is a sequentially-assigned number describing the various options for artwork, numbering, mag stripe, slot punching, etc.
20301 Nordhoff Street, Chatsworth, CA 91311 PHONE (818) 882-0020 • FAX (818) 882-7052 TOLL-FREE (800) 891-0020 www.securakey.com mail@securakey.com
FOR ORDERS: FAX (818) 206-6190 TOLL-FREE (877) 850-3449 E-mail: orders@securakey.com
* No charge for standard artwork: (blank with slot punch crosshairs (AF 5816), or blank with directional arrow (AF 4435).
** Style 20 uses Secura Key e*Tag® HF technology. HID® iCLASS is not available. Call for information on MIFARE or DESFire technology.
** In the Secura Key part numbering each letter describes specific card options. The example given has no arwork, card number matches internal code, laser engraved on back, no mag stripe and no slot
