Securakey Wiegand Card Part Numbering Scheme Guide
Open the original PDF document
View PDFWiegand Swipe Card Part Numbering and Equivalency Chart
| WIEGAND SWIPE CARDS: PART NUMBERING SCHEME | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Technology | Config. | Style |
Reader
Type |
Artwork | Numbering |
Number
Loc. |
Finish |
Mag
Stripe |
Mag
Stripe Location |
Slot | |
|
WC-
Wiegand |
CI-
Card |
10
(30 mil) |
S-
Swipe |
C-
Custom |
M -
Match Internal - ID only |
F-
Front |
GA-
Gloss All |
B-
on Back |
T-
Top |
P-
Portrait |
|
|
CS-
Code Strip |
11
(37 mil) |
l-
Insert |
S-
Secura Key Logos |
N -
Non-matching ID only |
B-
Back |
MA-
Matte All |
F-
on Front |
B-
Bottom |
L-
Landscape |
||
|
14
47 mil (tuffcard) |
N-
None* (blank) |
F-
ID Matching, w/ Facility Code |
GF-
Gloss front |
N-
No Stripe |
N-
No Stripe |
N-
No Slot |
|||||
|
16
**
47 mil (prox+wieg) |
S -
ID Matching, w/FC & Sales Order # |
GB-
Gloss Back |
|||||||||
|
20***
37 mil (HF+ wieg) |
O -
ID Matching, Omit FC with Sales Order # |
||||||||||
Example Part Number : WCCI-11-SNMBGANNL = Wiegand Card, 37 mil thick, swipe reader, no artwork, laser numbering matches internal code, number on back, glossy both sides, no magstripe, no magstripe location, landscape slot.
NOTE: Secura Key does not offer "zero-gap" Wiegand card encoding; if gaps in number sequence occur due to production fallout, additional cards will be supplied to fulfill the quantity ordered.
| WIEGAND SWIPE CARDS: HID® VS SECURA KEY PART NUMBER EQUIVALENCY | |||||||
|---|---|---|---|---|---|---|---|
| HID* | Description | Secura Key** | |||||
| 100nnnn | 30 mil Wiegand card, matte finish | WCCI-10xxxxMAxxx | |||||
| 109nnnn | 30 mil Wiegand card, glossy finish | WCCI-10xxxxGAxxx | |||||
| 110nnnn | 37 mil Wiegand card, matte finish | WCCI-11xxxxMAxxx | |||||
| 119nnnn | 37 mil Wiegand card, glossy finish | WCCI-11xxxxGAxxx | |||||
| 140nnnn | 47 mil Wiegand card, matte finish, extra thick "tuffcard" | WCCI-14xxxxMAxxx | |||||
| 149nnnn | 47 mil Wiegand card, glossy finish, extra thick "tuffcard" | WCCI-14xxxxGAxxx | |||||
| 160nnnn | 47 mil Wiegand + proximity card, matte finish | WCCI-16xxxxMAxxx | |||||
| 169nnnn | 47 mil Wiegand + proximity card, matte finish | WCCI-16xxxxGAxxx | |||||
* In the HID part numbering, nnnn is a sequentially-assigned number describing the various options for artwork, numbering, mag stripe, slot punching, etc.
20301 Nordhoff Street, Chatsworth, CA 91311 PHONE (818) 882-0020 • FAX (818) 882-7052 TOLL-FREE (800) 891-0020 www.securakey.com mail@securakey.com
FOR ORDERS: FAX (818) 206-6190 TOLL-FREE (877) 850-3449 E-mail: orders@securakey.com
* No charge for standard artwork:(blank with slot punch crosshairs (AF 5816), or blank with directional arrow (AF 4435) or blank with small Secura Key logo on back (AF 7883).
** Verify that your printer can accept 47 mil thickness if these cards are to be Dye Sublimation printed with Photo ID.
** Style 20 can use Secura Key e*Tag® HF technology or most other 13.56 MHz technologies except HID® iCLASS. Call for information on MIFARE or DESFire technology.
** In the Secura Key part numbering each letter describes specific card options. To complete the part number with the options you require, use the chart at the top of the page.
