APPLICATIONS BULLETIN #10
Subject: RS-232 WIRING FOR RKAT AUDIT TRAIL MODULE
The RKAT Installation Manual assumes that you will splice additional wire into the supplied DB25 connector and cable assembly and does not include detailed instructions for building your own cable.
Use the table below for the correct pin number connections. For a PC, use a DB9 or DB25 Female connector; for a Serial Printer, use a DB25 Male connector.
| RS-232 Wiring for RKAT Audit Trail | |||
|---|---|---|---|
| RKAT WIRE COLOR | FUNCTION | DB9 PINS | DB25 PINS |
| Red | RXD | 3 | 2 |
| Orange | CTS | 4 | 20 |
| Brown | TXD | 2 | 3 |
| Black | GND | 5 | 7 |
DATE: 1/5/98 REV.: -- AF#: 4781
