Securakey Quick Reference Guide – Proximity
Open the original PDF document
View PDFQuick Reference Guide - Proximity Smart. Reliable. Secure.
| Stand Alone Proximity Solutions | SYSKIT (Pre-packaged Kits) | ||||
|---|---|---|---|---|---|
| How many doors? | 1 | 1 |
2+ doors.
(1 kit for ea. 2 doors) |
2+ doors.
(1 kit for ea. 2 doors) |
|
| Audit trail required? | No | No | Yes | Yes | |
|
Future Expansion
Considerations? |
Yes | Yes | Yes | Yes | |
| Product | |||||
| RK65K | RK65KS | SYSKIT1 | SYSKIT2 | ||
|
Product
(choose one) |
|||||
| Description |
Prox Standalone
Single-Door Access Control Unit, Wiegand output |
Prox Standalone
Single-Door Access Control Unit, Wiegand output |
Access Control Kit -
2-door panel, software, cable, DC supply, connector, 2 mullion readers, 25 cards |
Access Control Kit -
2-door panel, software, cable, DC supply, connector 2 wall readers, 25 cards |
|
| Total number of Users | 65535 | 65535 | |||
| Facility Code | 10 | 16 | |||
| Programming | |||||
| Programming via | Hand Held Programmer (RK-HHP) | PC (SK-NET Software) | |||
| Audit Trail | No | SK-NET Software included in kit | |||
| Credentials | |||||
| Molded clamshell (RKCM-02) | Molded clamshell (RKCM-02) | ||||
|
Type of Credentials
(choose one) |
ISO Card (RKCI-02) | ISO Card (RKCI-02) | |||
| Key Tag (RKKT-02) | Key Tag (RKKT-02) | ||||
| SK-ACP Control Panel | |||||
|
•
• 65000 Card Capacity • 4800 Stored Events • |
2-Door Panel Supports 2 Wiegand output Card Readers
16 Time Zones; Weekly Schedule and 32 Holidays |
•
TCP/IP Capability for LAN Connectivity • Easily add panels with RS-485 Bus • Put the panels where you want them |
|||
| RS485 Connection | Included in panel, NETCONV required to connect RS-485 to PC | ||||
| Wireless Connection | Requires SK-WLS-MOD - one per panel | ||||
| Requires SK-LAN-MOD - one per panel | |||||
| Proximity Card Readers | ||||||
|---|---|---|---|---|---|---|
| Description | S-Mini Mullion | Wall Switch | Long Range | |||
|
Product
(Choose One) |
RKWM | RKWS | RKWL | |||
| Color | Black | Black/Beige | Black | |||
| Dimensions | 3.5" x 1.6" x 0.6" | 4.5" x 3.2" x 0.84" | 12" x 12" x 1.2" | |||
| Environmental | Indoor/Outdoor ( -40°F to +158°F or -40°C to +70°C) | |||||
| Read Range |
Molded Card up to 6"
ISO Card/KeyTag up to 5" |
Molded Card up to 8"
ISO Card/KeyTag up to 5" |
Molded Card up to 36"
ISO Card/KeyTag up to 26" (Note: 2 or more RKWL readers must be 8' apart) |
|||
| Power Requirements | 40/90mA avg/peak @ 5-14VDC |
300/350mA avg/peak
(regulated) @ 12-14VDC |
||||
| Operating Mode | Read only, card data | |||||
| Operating Frequency | 125kHz | |||||
| Communications | Wiegand | |||||
| Cable Required | up to 500' 5-10 conductor / 18-22 AWG Shielded | |||||
| Warranty | Lifetime warranty | |||||
| Compatible Cards | Molded clamshell (RKCM-02), ISO (RKCI-02), Key Tag (RKKT-02) | |||||
| About Proximity Technology | ||||||
|
Mature, reliable, simple technology
125 KHz Card Technology - Passive RFID chip/antenna embedded in cards/keytags. RF field from reader powers chip which transmits ID to reader. Card Data is demodulated and output in Wiegand format. Card contains Facility Code and ID number only |
||||||
| SK-NET™ Software | ||||||
|
•
Full feature set included in basic software • Controls up to 200 doors on RS-485 twisted pair per location MLD Software available with multiple TCP/IP connection capability, allows Managed Access Control capability (RMR) |
•
• |
Client/Server for Multiple Workstations
Limited Use, 16 Time Zones, Real and Timed Anti-passback Set up Access Groups, User Groups, Reader Groups, include photos, badging (optional) |
||||
SALES:
Charlie Anthony, US Regional Sales Manager • cell: 818.400.7779 • canthony@securakey.com
SECURA KEY
More than 1 user? Requires SK-NET-MLD-CS-X software (X = 2,5,10,15)
•
Single location, single TCP/IP connection Requires SK-NET-DM (Available as free download)
or dial-up modem(s) - Managed Access Control? Requires SK-NET-MLD software
20301 Nordhoff Street, Chatsworth, CA 91311 (818) 882-0020 • FAX (818) 882-7052 • TOLL-FREE (800) 891-0020 Website: www.securakey.com • E-mail: mail@securakey.com
More than 1 location, multiple TCP/IP connections,
Easy to install, learn and expand: Keep it Simple!
