View PDFQuick Reference Guide Smart. Reliable. Secure.
| Stand-Alone Proximity Solutions | eAccess Kits | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| How many doors? | 1 | 1 | 1 | 1 | 2 | 2 |
2+ doors.
(1 kit for each 2 doors) |
||
| Number of Users more | |||||||||
| Future Expansion | |||||||||
| Product | Product | ||||||||
|
Product
(choose one) |
|||||||||
| Description |
Prox/PIN Standalone
Single-Door Access Control Unit |
Prox Standalone
Single-Door Access Control Unit |
Prox Standalone
Single-Door Access Control Unit, Wiegand output |
Prox Standalone
Single-Door Access Control Unit, Wiegand output |
Access Control Kit -
2-door panel, software, cable, DC supply, 2 mullion readers, 25 cards |
Access Control Kit -
2-door panel, software, cable, DC supply, 2 wall switch readers, 25 cards |
Access Control Kit -
2-door panel, DC supply, 2 mullion readers (no cards) |
||
| Programming | Programming | ||||||||
| Credentials | Credentials | ||||||||
| Molded clamshell (RKCM-01) | Molded clamshell (RKCM-02) | na | |||||||
|
Type of Credentials
(choose one) |
|||||||||
| Stand-Alone Proximity Solutions | eAccess Kits | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| How many doors? | 1 | 1 | 1 | 1 | 2 | 2 |
2+ doors.
(1 kit for each 2 doors) |
2+ doors.
(1 kit for each 2 doors) |
2 | 2 | |
| Audit trail required? | Yes/ No | Yes/ No | No | No | Yes | Yes | Yes | Yes | Yes | Yes | |
|
Number of Users more
than 600? |
No | No | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | |
|
Future Expansion
Considerations? |
No | No | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | |
| Product | Product | ||||||||||
| RK600 | RK600e | RK65K | RK65KS | eAccess 1 | eAccess 2 | eAccess 3 | eAccess 4 | eAccess 5 | eAccess 6 | ||
|
Product
(choose one) |
|||||||||||
| Description |
Prox/PIN Standalone
Single-Door Access Control Unit |
Prox Standalone
Single-Door Access Control Unit |
Prox Standalone
Single-Door Access Control Unit, Wiegand output |
Prox Standalone
Single-Door Access Control Unit, Wiegand output |
Access Control Kit -
2-door panel, software, cable, DC supply, 2 mullion readers, 25 cards |
Access Control Kit -
2-door panel, software, cable, DC supply, 2 wall switch readers, 25 cards |
Access Control Kit -
2-door panel, DC supply, 2 mullion readers (no cards) |
Access Control Kit -
2-door panel, DC supply, 2 wall switch readers (no cards) |
Access Control Kit -
2-door panel, software, cable, DC supply, 2 mullion readers (no cards) |
Access Control Kit
2-door panel, software, cable, DC supply, 2 wall switch readers (no cards) |
|
| Total number of Users | 600 | 65535 | 65535 | 65535 | 65535 | 65535 | 65535 | 65535 | |||
| Programming | Programming | ||||||||||
| Programming via | Built in keypad | Hand Held Programmer (RK-HHP) | PC | PC | PC | PC | PC | PC | |||
| Audit Trail | Audit Trail Module (RKAT): Available | — | — | SK-NET™ Software included in kit | Software not included | SK-NET™ Software included in kit | |||||
| Credentials | Credentials | ||||||||||
| Molded clamshell (RKCM-01) | Molded clamshell (RKCM-02) | na | |||||||||
|
Type of Credentials
(choose one) |
ISO Card (RKCI-01) | ISO Card (RKCI-02) | ISO Card (25 ETCI04 cards included in kit) | ISO Cards (specify number of ETCI04 cards-sold separately) | |||||||
| Key Tag (RKKT-01) | Key Tag (RKKT-02) | Key Tag (ETST03 or ETKT03-sold separately) | |||||||||
- Full feature set included in basic software •
- Controls up to 200 doors on RS-485 twisted pair per location •
- MLD Software available with multiple TCP/IP connection capability •
- Client/Server for Multiple Workstations •
- Limited Use, 16 Time Zones, Real and Timed Anti-passback •
- Set up Access Groups, User Groups, Reader Groups, include photos, badging (optional) •
- Easy to install, learn and expand: Keep it Simple! •
|
More than 1 location,
multiple TCP/IP connections, or dial-up modem(s)? |
Requires SK-NET-MLD software | RS485 Connection | Included in panel, NETCONV required to connect RS-485 to PC | |
|---|---|---|---|---|
| More than 1 user? | Requires SK-NET-MLD-CS-X software (X = 2,5,10,15) | Wireless Connection | Requires SK-WLS-MOD - one per panel | |
|
Single location, single
TCP/IP connection |
Requires SK-NET-DM (Available as free download) | Ethernet Connection | Requires SK-LAN-MOD - one per panel | |
SK-NET™ Software SK-ACP Control Panel
- 2-Door Panel Supports 2 Wiegand output Card Readers •
- 65000 Card Capacity •
- 4800 Stored Events •
- 16 Time Zones; Weekly Schedule and 32 Holidays •
- TCP/IP Capability for LAN Connectivity •
- Easily add panels with RS-485 Bus •
- Put the panels where you want them •
| Requires SK-NET-MLD software | RS485 Connection | Included in panel, NETCONV required to connect RS-485 to PC |
|---|---|---|
| Proximity Card Readers | E*Tag® Contactless Smart Card Readers | |||||||
|---|---|---|---|---|---|---|---|---|
| Product | RKWM | RKWS | RKWL | ET8-RO-W-D | ET8-RO-W-M | ET4-WXM | ET4-WXS | |
| Description | S-Mini Mullion | Wall Switch | Long Range | Decorator | Standard Mullion | S-Mini-Mullion | Wallswitch | |
| Image | ||||||||
| Color | Black | Black/Beige | Black | White/Ivory | Black | Black | Black/Beige | |
| Dimensions | 3.5" x 1.6" x 0.6" | 4.5" x 3.2" x 0.84" | 12" x 12" x 1.2" | 4.5" x 2.75" x 0.7" | 4.38" x 1.74" x 0.9" | 3.5" x 1.6" x 0.6" | 4.5" x 3.2" x 0.84" | |
| Environmental | Indoor/Outdoor ( -40°F to +158°F or -40°C to +70°C) |
Indoor Only
(-40°F to +158°F or -40°C to +70°C) |
Indoor/Outdoor ( -40°F to +158°F or -40°C to +70°C) | |||||
| Read Range |
Molded Card up to 6"
ISO Card/KeyTag up to 5" |
Molded Card up to 8"
ISO Card/KeyTag up to 5" |
Molded Card up to 36"
ISO Card/KeyTag up to 26" (Note: 2 or more RKWL readers must be 8' apart) |
ISO Card up to 4" KeyTag up to 2.5" | ||||
| Power Requirements | 40/90mA avg/peak @ 5-14VDC |
300/350mA avg/peak
(regulated) @ 12-14VDC |
30/65mA avg/max @ 5-14VDC | |||||
| Operating Mode | Read only, card data | Read only, card data | Read only, card data | Read only, card data |
Read only, card data, UID or Wiegand;
Read-write (host managed) RS-485 |
|||
| Operating Frequency | 125kHz | 125kHz | 125kHz | 13.56Mhz | 13.56Mhz | 13.56Mhz | 13.56Mhz | |
| Communications | Wiegand |
Wiegand
Wiegand, RS-485 (point-to-point) |
||||||
| Cable Required | up to 500' 5-10 conductor / 18-22 AWG Shielded | up to 500' 5-10 conductor / 18-22 AWG Shielded | ||||||
| Warranty | Lifetime warranty | Lifetime warranty | ||||||
| Molded clamshell (RKCM-02) | NA | |||||||
| Compatible Cards | ISO (RKCI-02) | ISO Cards (ETCI04) | ||||||
| Key Tag (RKKT-02) | Key Tag (ETST03 or ETKT03) | |||||||
| About Proxii | ||
Mature, reliable, simple technology 125 KHz Card Technology - Passive RFID chip/antenna embedded in cards/keytags. RF field from reader powers chip which transmits ID to reader. Card Data is demodulated and output in Wiegand format. Card contains Facility Code and ID number only
| Proximity Card Readers | E*Tag® Contactless Smart Card Readers | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Product | RKWM | RKWS | RKWL | ET8-RO-W-D | ET8-RO-W-M | ET4-WXM | ET4-WXS | |||
| Description | S-Mini Mullion | Wall Switch | Long Range | Decorator | Standard Mullion | S-Mini-Mullion | Wallswitch | |||
| Image | ||||||||||
| Color | Black | Black/Beige | Black | White/Ivory | Black | Black | Black/Beige | |||
| Dimensions | 3.5" x 1.6" x 0.6" | 4.5" x 3.2" x 0.84" | 12" x 12" x 1.2" | 4.5" x 2.75" x 0.7" | 4.38" x 1.74" x 0.9" | 3.5" x 1.6" x 0.6" | 4.5" x 3.2" x 0.84" | |||
| Environmental | Indoor/Outdoor ( -40°F to +158°F or -40°C to +70°C) |
Indoor Only
(-40°F to +158°F or -40°C to +70°C) |
Indoor/Outdoor ( -40°F to +158°F or -40°C to +70°C) | |||||||
| Read Range |
Molded Card up to 6"
ISO Card/KeyTag up to 5" |
Molded Card up to 8"
ISO Card/KeyTag up to 5" |
Molded Card up to 36"
ISO Card/KeyTag up to 26" (Note: 2 or more RKWL readers must be 8' apart) |
ISO Card up to 6"
ISO Card up to 4" KeyTag up to 2.5" KeyTag up to 3.5" |
||||||
| Power Requirements | 40/90mA avg/peak @ 5-14VDC |
300/350mA avg/peak
(regulated) @ 12-14VDC |
30/65mA avg/max @ 5-14VDC
50/90mA avg/max @ 5-14VDC |
|||||||
| Operating Mode | Read only, card data | Read only, card data | Read only, card data | Read only, card data |
Read only, card data, UID or Wiegand;
Read-write (host managed) RS-485 |
|||||
| Operating Frequency | 125kHz | 125kHz | 125kHz | 13.56Mhz | 13.56Mhz | 13.56Mhz | 13.56Mhz | |||
| Communications | Wiegand |
Wiegand
Wiegand, RS-485 (point-to-point) |
||||||||
| Cable Required | up to 500' 5-10 conductor / 18-22 AWG Shielded | up to 500' 5-10 conductor / 18-22 AWG Shielded | ||||||||
| Warranty | Lifetime warranty | Lifetime warranty | ||||||||
| Molded clamshell (RKCM-02) | NA | |||||||||
| Compatible Cards | ISO (RKCI-02) | ISO Cards (ETCI04) | ||||||||
| Key Tag (RKKT-02) | Key Tag (ETST03 or ETKT03) | |||||||||
| About Proximity Technology | About Smart Card Technology: | |||||||||
Works just like Prox with the benefit of higher security and more capabilities 13.56 MHz Contactless Smart Card Technology - Passive RFID chip/antenna embedded in cards/keytags. RF field from reader powers chip which transmits ID to reader. DES Encrypted Card Data is demodulated, decrypted, and output in Wiegand format. Card contains additional data storage capacity
