Securakey ETag Card and Tag Data Sheet

e * Tag^® Card & Tag Specifications

STANDARD PRODUCTS

Secura Key manufactures a variety of plastic cards and tags with HF (13.56 MHz) and UHF (900 MHz) transponder inlays. Certain standard shapes and inlay types are available.

PACKAGE D	DIMENSIONS
ETCI/	ISO Standard thickness,	0.033"	(0.84mm)	thick
ASCI	CR80 dimensions;	3.375"	(85.73mm)	long
	looks like a credit card.	2.125"	(53.98mm)	wide
ETST/	Standard; designed to hang on	0.067"	(1.70mm)	thick
ASST	a key ring.	2.205"	(56.00mm)	long	0
	3	1.102"	(27.99mm)	wide
			,
ETKT/	Special; designed to hang on	0.067"	(1.70mm)	thick		Diagrams To
ASKT	a key ring.	2.125"	(53.98mm)	long	(0	Scale, but Not Actual Size
		1.102"	(27.99mm)	wide
ETPT	Made for attachment	0.067"	(1.70mm)	thick
	to pallets, plastic totes,	2.938"	(74.63mm)	long
	etc., with two holes.	1.313"	(33.35mm)	wide
ETAT	Adhesive Tag	0.015"	(0.38mm)	thick
		1.73"	(43.94mm)	long
		0.95"	(24.13mm)	wide

<u>INLAYS</u>

111L/110
ETCI02-1	45mm X 76mm ISO 15693 2K bit
ETCI04-5	34mm X 65mm ISO 15693 2K bit	Standard for ETCI
ETCI14-1	45mm X 76mm ISO 14443 1K bit
ETST03-2	22.5mm X 38mm ISO 15693 2K bit	Standard for ETST, ETKT & ETPT
ETKT03-9	22.5mm X 38mm ISO 15693 2K bit
ETPT03-9	22.5mm X 38mm ISO 15693 2K bit
ETAT03-2	24mm X 44mm ISO 15693 512 bit	Standard for ETAT
ASCI05 / 06	71.20mm X 22.4mm ISO UHF Gen 2 EPC
ASST02 / 03	32.5mm x 20.5mm ISO UHF Gen 2 EPC
ASKT03 / 04	32.5mm x 20.5mm ISO UHF Gen 2 EPC

Custom Products

Secura Key can quote on any type of transponder packaging requirements:

• Special form factors
• Packaging inlays by various manufacturers
• ♦ Special encoding, with or without encryption
• Custom graphics and printing
• Variable data (i.e. bar codes, sequential numbering, etc.)
• ♦ Magnetic stripes, multi-technology, signature panels, etc.
