Schlage ND Series Lock Functions Guide

Open the original PDF document

View PDF

Schlage ND Series Lock Functions Guide

Non Keyed

ANSI
No. 		Function Function Description Link to Lock
F75 ND10S - Passage
Latch 		Both levers always unlocked. Click here to view Schlage
ND10S
F89 ND12D - Exit Lock
  • Outside lever always fixed.
  • Inside lever always free for immediate egress.
Click here to view Schlage
ND12D
- ND25D - Exit Lock
with Blank Plate
Outside
  • Blank plate outside.
  • Inside lever always free for immediate egress.
Click here to view Schlage
ND25D
F77 ND30D - Patio
Lock
  • Push button locking.
  • Turning inside lever or closing
    door releases button, preventing
    a lock-out.
  • Inside lever always unlocked for
    immediate egress.
Click here to view Schlage
ND30D
F76 ND40S -
Bath/Bedroom
Privacy Lock
  • Push-button locking.
  • Unlocked from outside with a small screwdriver.
  • Turn inside lever or close door to release button.
  • Inside lever always free for immediate egress.
Click here to view Schlage
ND40S
- ND44S - Hospital
Privacy Lock
  • Push-button locking.
  • Unlocked from outside by
    turning emergency turnbutton.
  • Turn inside lever or close door
    to release button.
  • Inside lever always free for
    immediate egress.
Click here to view Schlage
ND44S
- ND45 - Timeout
Lock
  • Caretaker side: Pushing and holding button will lock inside lever (detention side) until released. Lever always retracts latch.
  • Detention side: Lever retracts latch unless outside button is depressed. Vandlgard allows inside spindle to disengage from latch when locked
Click here to view Schlage ND45

Non Keyed (Contd...)

ANSI
No. 		Function Function Description Link to Lock
- ND170 - Single
Dummy Trim 		• Dummy trim for one side of
door.
• Used for door pull or as
matching inactive trim. 		Click here to view Schlage
ND170
- ND172 - Double
Dummy Trim 		• Dual dummy trim for both sides
of the door.
• Used for door pull or as
matching inactive trim 		Click here to view Schlage
ND172

Keyed

ANSI
No. 		Function Function Description Link to Lock
F82 ND50PD -
Entrance/Office
Lock 		• Push-button locking.
• Push-button locks outside lever
until it is unlocked with key or by
turning inside lever.
• Inside lever always free for
immediate egress. 		Click here to view Schlage
ND50PD
F109 ND53PD -
Entrance Lock 		• Turn/push-button locking:
Pushing and turning the button
locks the outside lever, requiring
use of a key until the button is
manually unlocked.
• Push-button locking: Pushing
button locks outside lever until
unlocked by key or by turning the
inside lever.
• Inside lever always free for
immediate egress 		Click here to view Schlage
ND53PD
F88 ND60PD -
Vestibule Lock 		• Latch retracted by key from
outside when outside lever is
locked by key in inside lever.
• Inside lever always free for
immediate egress. 		Click here to view Schlage
ND60PD
- ND60PD -
Vestibule with
Closed Lever 		• Same as ND60 except outside
lever is closed. Inside lever
always unlocked for immediate
egress. 		Click here to view Schlage
ND60PD
F91 ND66PD - Store
Lock 		• Key in either lever locks or
unlocks both levers. 		Click here to view Schlage
ND66PD

Keyed (Contd...)

ANSI
No. 		Function Function Description Link to Lock
F90 ND73PD -
Corridor Lock 		• Locked or unlocked by key from
outside.
• Push-button locking from
inside.
• Turn inside lever or close door
to release button.
• When outside lever is locked by
key it can only be unlocked by
key.
• Inside lever always free for
immediate egress. 		Click here to view Schlage
ND73PD
- ND75PD -
Classroom
Security Lock 		• Key in either lever locks or
unlocks outside lever.
• Inside lever always free for
immediate egress. 		Click here to view Schlage
ND75PD
F86 ND80PD -
Storeroom Lock 		• Outside lever is fixed.
• Entrance by key only.
• Inside lever always free for
immediate egress 		Click here to view Schlage
ND80PD
F87 ND82PD -
Institution Lock 		• Both levers always fixed.
• Entrance by key in either lever 		Click here to view Schlage
ND82PD
- ND85PD - Faculty
Restroom Lock 		• Outside lever is fixed. •
Entrance by key only.
• Visual occupancy indicator,
allowing only emergency key to
operate.
• Turn inside lever or close door
to unlock.
• Rotation of inside spinnerbutton
enables lock-out feature.
• Inside lever always free for
immediate egress.
• Not available with
interchangable core cylinders. 		Click here to view Schlage
ND85PD
- ND25x70PD -
Classroom Exit
Lock 		• Blank plate outside.
• Key locks or unlocks inside
lever. 		Click here to view Schlage
ND25x70PD
- ND25x80PD -
Storeroom Exit
Lock 		• Blank plate outside.
• Key in fixed inside lever retracts
latch. 		Click here to view Schlage
ND25x80PD
- ND70x80PD -
Classroom By
Storeroom Lock 		• Key locks and unlocks outside
lever.
• Key in fixed inside lever retracts
latch. 		Click here to view Schlage
ND70x80PD

Locks with Vandlgard Levers

ANSI
No. 		Function Function Description Link to Lock
F82 ND91PD -
Entrance/Office
Lock 		• Push-button locking.
• Push-button disengages
outside lever until unlocked with
key or by turning inside lever.
• Vandlgard allows outside
spindle to disengage from latch
when locked.
• Inside lever always free for
immediate egress. 		Click here to view Schlage
ND91PD
F109 ND92PD -
Entrance Lock 		• Turn/push-button locking:
Pushing and turning button
disengages outside lever,
requiring using of key until button
is manually unlocked.
• Push-button locking: Pushing
button disengages outside lever
until unlocked by key or by
turning inside lever.
• Vandlgard allows outside
spindle to disengage from latch
when locked.
• Inside lever always free for
immediate egress. 		Click here to view Schlage
ND92PD
F88 ND93PD -
Vestibule Lock 		• Latch retracted by key from
outside when outside lever is
disengaged by key in inside
lever.
• Vandlgard allows outside
spindle to disengage from latch
when locked.
• Inside lever always free for
immediate egress. 		Click here to view Schlage
ND93PD
F84 ND94PD -
Classroom Lock 		• Outside lever disengaged and
unlocked by key.
• Vandlgard allows outside
spindle to disengage from latch
when locked.
• Inside lever always free for
immediate egress. 		Click here to view Schlage
ND94PD
- ND95PD -
Classroom
Security Lock 		• Key in either lever locks or
unlocks outside lever.
• Vandlgard allows outside
spindle to disengage from latch
when locked.
• Inside lever always free for
immediate egress. 		Click here to view Schlage
ND95PD

Locks with Vandlgard Levers (Contd...)

ANSI
No. 		Function Function Description Link to Lock
F86 ND96PD -
Storeroom Lock 		• Outside lever always
disengaged.
• Entrance by key only.
• Vandlgard allows outside
spindle to disengage from latch
when locked.
• Inside lever always free for
immediate egress. 		Click here to view Schlage
ND96PD
F90 ND97PD -
Corridor Lock 		• Locked or unlocked by key from
outside.
• Push-button locking from
inside.
• Turning inside lever or closing
door releases button.
• When outside lever is locked by
key it can only be unlocked by
key.
• Vandlgard allows outside
spindle to disengage from latch
when locked.
• Inside lever always free for
immediate egress 		Click here to view Schlage
ND97PD

Wired Electrified Locks

ANSI
No. 		Function Function Description Link to Lock
- ND12EL - Keyless
Electrified Exit 		• Outside lever continuously
locked (EL) by 12-24V DC.
• EL is fail safe (power fail
unlocks outside lever).
• Inside lever always free for
immediate egress. 		Click here to view Schlage
ND12EL
- ND12EU - Keyless
Electrified Exit 		• Outside lever continuously
unlocked (EU) by 12-24V DC.
• EU is fail secure (power fail
locks outside lever).
• Inside lever always free for
immediate egress. 		Click here to view Schlage
ND12EU
- ND80EL -
Electrified
Storeroom 		• Outside lever continuously
locked (EL) by 12-24V DC.
• EL is fail safe (power fail
unlocks outside lever).
• Key outside serves as
mechanical override.
• Inside lever always free for
immediate egress. 		Click here to view Schlage
ND80EL

Wired Electrified Locks (Contd...)

ANSI
No. 		Function Function Description Link to Lock
- ND80EU -
Electrified
Storeroom 		• Outside lever continuously
unlocked (EU) by 12-24V DC.
• EU is fail secure (power fail
locks outside lever).
• Key outside serves as
mechanical override.
• Inside lever always free for
immediate egress. 		Click here to view Schlage
ND80EU
- ND96EL -
Electrified
Storeroom with
Vandlgard 		• Adds Vandlgard to ND80EL/EU.
• Vandlgard allows outside
spindle to disengage from latch
when locked, limiting the ability
of vandals to apply excessive
force to the chassis. See page
16 for more details. 		Click here to view Schlage
ND96EL
- ND96EU -
Electrified
Storeroom with
Vandlgard 		• Adds Vandlgard to ND80EL/EU.
• Vandlgard allows outside
spindle to disengage from latch
when locked, limiting the ability
of vandals to apply excessive
force to the chassis. See page
16 for more details. 		Click here to view Schlage
ND96EU
