Schlage JD60 JD62 JD81 Door Manufacturer Template Metal Square Corner

JD-Series

Models JD60, JD62, JD81

Door Type: Metal, Flat or Beveled Door Thickness: 1C\," (35 mm)–1C\v" (44 mm) Faceplate: Square Corner, 1" (25 mm) wide Backsets: 23 / 8," (60 mm), 23 / 4" (70 mm)

For metal door installations, suitable reinforcement is required to support latch in center of door and to prevent lateral movement

Dimensions shown in parentheses () are in millimeters. Template is not to scale. Standard backset in bold.

Door preparation template
