Schlage ExpressTM

Offline Access Control Software

Schlage ExpressTM Offline Access Control Software provides a simple and effective means to manage access control within your facility. It supports Schlage offline locks including the CO-200, CO-220 and AD-200, as well as the CT5000 controller. Schlage Express is recommended for smaller facilities with basic access control needs.

It allows you to quickly enter or delete users and access points. It is compatible with a variety of credential options including PIN codes, iButtons, magnetic stripe, proximity and smart cards. For added security, dual authentication (card + PIN) is also supported.

Reporting capability is available to show audit trails retrieved, access privileges granted, and time functions established by either user or door.

Features and benefits

• § A variety of credential functions are supported including normal, toggle, one time and pass through
• § Auto unlock schedules allows weekly repeating for automatic locking and unlocking of doors (up to 16 defined per system; up to 8 assigned per lock)
• § Supports magnetic stripe, proximity and smart cards
• § Supported devices include CO-200, CO-220, AD-200, CM, KC-2, CT-1000, CT5000 and BE367
• § Supports Windows 10, Windows XP, Windows 7 and Windows 8 Please note that Schlage Express Software is NOT supported on the Home and Starter Versions of the Windows Operating Systems.
• § User times zones- limits the hours and days a user can access assigned points (Up to 8)
• § Holidays suspends normal operations for user defined periods per door during non-normal days (Up to 16)
• § Users/audits and lock support
• § 2,000 Users/audits and 50 locks/devices
• § 1,000 Users/audits and 100 locks/devices
• § Supports 12 button keypad with up to 6 digit PIN codes
• § Duplicate PIN notification feature

Specifications
Hardware	Intel Pentium II processor (Pentium III or IV recommended), CD-ROM, mouse or compatible pointing device, VGA or Super VGA monitor, keyboard
Hard disk space	250 MB for software; will require additional space for stored data
Memory	256 MB RAM minimum or the memory required for the operating system, whichever is greater
Operating system	Microsoft Windows 10, Windows XP, Windows 7 and Windows 8
	Please note that Schlage Express Software is NOT supported on the Home and Starter Versions of the Windows Operating Systems.
	Reports with the built-in viewer Internet Explorer 6 or higher must be installed.
Required for programming	For offline locking system programming using a Schlage approved HHD device, the following is required:
	§ Available USB port on the PC § Approved HHD device with installed communications software and interface cables from Schlage
	For offline legacy locking system programming done directly from the PC, the following is required:
	§ Available USB port on the PC § Programming interface cables

Ordering information

§ SXPR-SFT-1 - Schlage Express software only

Accessories

• § HHD KIT Handheld device to manage Schlage offline locks (USB cable included for managing AD Series and CO Series locks)
• § HHD-USB Additional or replacement cable used to connect HHD to AD Series and CO Series products
• § HH-Serial Serial cable used in conjunction with HHD KIT and CIP for managing legacy Schlage offline locks
• § P512112 Computer interface module used in conjunction with HH-Serial cable for managing legacy Schlage offline locks
• § P101203 Computer Interface module with ibutton reader used in conjunction with HH-Serial Cable for managing legacy Schlage offline locks
• § P394548 Female/female serial cable. Used to connect computer interface module to laptop/PC
• § SDB9USBCBL Six inch cable adapter allows a serial port device to be used with a USB port device (for use with PS12112)
• § CRP2 Proximity credential enrollment reader. Used to read proximity data for enrollment into Schlage Express 4.0 and higher
• § CRM2 Magnetic stripe credential enrollment reader. Used to read magnetic stripe data for enrollment into Schlage Express 4.0 and higher
