S6000DE Delay electronics packaged on a 3-gang wall plate for recessed wall mounting or surface wall mounting with optional junction box. Features include: 15 second exit delay, 1 or 2 second nuisance delay, code dependent exit delay and nuisance times. Keypad for violation reset, momentary bypass and on-off; Voice Annunciation and digital countdown display with door open indicator. Status and remote control inputs are standard Single: 24VDC @ 430 mA Tandem: 24VDC @ 680 mA
Vertical Rod
101-KDE
101-DE with SHD-J
DEC-J
Specify Trim for S61 and S62 - See page 45
DE Electrification of master exit device and wall mount controller with keypad control and reset 1,386.00 KDE Electrification of master exit device and wall mount controller with both keypad and key switch control and reset, less cylinder - order cylinder seperte: 1,497.00
CYL-6KDQ 6 pin, 1.125" mortise cylinder, keyed different, dull chrome add 49.00 CYL-6KAQ 6 pin, 1.125" mortise cylinder, keyed alike, dull chrome add 49.00
DES For pair of doors, additional exit device equipped with delayed egress mechanism, less controller. Must be ordered together with DE and device. 555.00
SPECIFY OPERATION
NA IBC, IFC, NFPA compliant, Field Selectable 15 to 30 second Exit Delay, 1 or 2 Nuisance Delay N/C If no Code is specified - NA is the SDC Standard Operations Mode for this product
NC IBC, IFC, NFPA 101, NFPA 1-UFC, UBC, SBC compliant, Fixed 15 second Exit Delay, 0/1 Nuisance Delay, Calif. Building Code OSHPD/Manual Power Up N/C ND IBC, IFC, NFPA 101, NFPA 1-UFC, UBC, SBC compliant, Fixed 15 second Exit Delay, 0/1 Nuisance Delay N/C BC BOCA National Building Code/City of Chicago Compliant, Fixed 15 second Exit Delay, 0 Nuisance Delay, N/C
Auto Reset 30 seconds BD BOCA National Building Code, Fixed 15 second Exit Delay, 0/1 Nuisance Delay, Auto Reset 30 seconds N/C
| SPECIFY TRIM (Mortise Only) ALSO SEE PAGE 47 | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| EE | Eclipse Escutheon |
Galaxy Escutheon
GE |
N/C | ||||||
| TRIM OPTIONS | Add to List | ||||||||
| CYL-6KDQ | 6 pin, 1.125" mortise cylinder, keyed different, dull chrome | 49.00 | |||||||
| CYL-6KAQ | 6 pin, 1.125" mortise cylinder, keyed alike, dull chrome | 49.00 | |||||||
| RIM-CYL-KA | Rim Cylinder for 03 Function, keyed alike - see page 45 for more info | 37.00 | |||||||
| SPECIFY OPTIONS FOR CONTROLER | LIST | |||
|---|---|---|---|---|
| DEC-J | 3 Gang Interior - 101-DEC | 100.00 | SHD-J Shroud for outdoor Use DEC-J | 100.00 |
