ROLLER LATCHES STAINLESS STEEL ROLLER LATCHES

HARDWARE

IDC Roller Latches are easily adjustable for roller projection for proper contact between roller and frame strike. Adjustment is made with 2 screws on the face of the roller latch body. Maximum roller projection is 5/16". The nylon roller provides durability and quiet operation. All units are stainless steel construction. Meets ANSI/BHMA A156.16, E19091. Available in most architectural finishes. Custom strikes available.

• Cast full lip strike 1-11/16" wide x 2-1/4"
• Latch face 1" x 3-3/8"
• Fasteners Body (2) #10 x 3/4" FH SMS Strike (2) #8 x 3/4" FH SMS

1890 1890S

• Custom Strike for double acting doors
• Latch face 1" x 3-3/8"
• Fasteners Body (2) #10 x 3/4" FH SMS Strike #8 x 3/4" FH SMS (Quantity determined by width)

• ASA Strike 1-1/8" wide x 4-3/4"
• Latch face 1" x 3-3/8"
• Fasteners Body (2) #10 x 3/4" FH SMS Strike (2) #12-24 x 3/8" FH MS

1891 1892

• T Strike 1-1/8" wide x 2-3/4"
• Latch face 1" x 3-3/8"
• Fasteners Body (2) #10 x 3/4" FH SMS Strike (2) #10 x 3/4" FH SMS

• With integrated angle stop
• Mounts in header with strike at top of door
• Cast strike 1-1/8" wide x 2-1/4"
• Latch face 1-1/2" x 4-1/2"
• Fasteners Body (2) #10 x 3/4" FH SMS Strike (2) #10 x 3/4" FH SMS

1893 1894

• Extended cast strike 2-1/8" wide x 2-1/4"
• Latch face 1" x 3-3/8"
• Fasteners Body (2) #10 x 3/4" FH SMS Strike (2) #8 x 3/4" FH SMS

1895

• Roller projection can be adjusted by turning the knurled knob at the back of the latch
• Maximum roller projection 1/2" to compensate for different door clearances
• Uses standard heavy duty cylindrical lock cut-out
• Standard strike 1-1/8" wide x 2-3/4"
• Body 1-1/8" wide x 2-1/4"

• For roller latch with ASA strike order 1896 (1-1/4" wide x 4-7/8")
• Fasteners Body (2) #8 x 3/4" FH SMS Strike (2) #10 x 3/4" FH SMS ASA Strike #12-24 x 3/4 FH SMS
