STRIKES & RESCUE STOPS

DUST PROOF STRIKE

1870 FOR DOORS WITHOUT THRESHOLDS 1872 FOR DOORS WITH THRESHOLDS

• For use with any ABH flush bolts
• Prevents dirt, dust and debris from floor clogging strikes

COMBO DOUBLE LIPPED STRIKE AND RESCUE STOP

• For 5-3/4" and 6-3/4" frame with 1-3/4" door
• To be used with ABH 0127 or 0128 center hung pivot sets. Ideal for hospital or nursing home bathroom doors. Stop can be rotated into frame to allow center hung or 1/8" inset double acting doors to swing out in case of emergency.
• Available in US32D, US32, US3, US4, US10B.
• .093 thick material
• Meets ANSI A1882
• Custom sizes available
• Holdback option available (CR4550,60,70,80 only) (handed)

CR4550/60 CR4570/80

FOR CENTER HUNG DOORS

• CR4550/CR4591 5-3/4" x 2-3/4"
• CR4560/CR4592 6-3/4" x 2-3/4"

FOR 1/8" INSET DOOR

• CR4570/CR4594 5-3/4" x 2-3/4"
• CR4580/CR4593 6-3/4" x 2-3/4"

CR4591/92 CR4594/93

4590 RESCUE STOP

FOR CONVERTING A DOUBLE ACTING CENTER HUNG DOOR TO SINGLE ACTING

• Allows door to swing open in opposite direction if a hospital or nursing home patient falls and obstructs the normal swing of the door
• Meets ANSI Spec A1882
• Stainless steel, US32D standard
• Pushing in on the spring loaded stop allows emergency operation of the door. Stop automatically returns to normal position when released
