Push Button Switch Cross Reference

PUSH BUTTONS

		1						l
DESCRIPTION	CAMDEN	RCI	SECURITRON	SCHLAGE	SDC	DYNALOCK	ROFU	ALARM CONTROLS
All-Active 1 3/4 x 4 1/2" Push Plate Plain or w/Logo Narrow Stainless Steel	CM-25	940NHP	N/A	N/A	N/A	6805	N/A	PNI
All-Active 4 1/2" Round Push Plate Plain or w/Logo Stainless Steel	CM-40	950HP4	N/A	N/A	N/A	N/A	N/A	N/A
All-Active 4 1/2" Square Push Plate Plain or w/Logo Stainless Steel	CM-45	N/A	N/A	N/A	N/A	6901	N/A	PD1
All-Active 6" Round Push Plate Plain or w/Logo Stainless Steel	CM-60	950HP6	N/A	N/A	N/A	N/A	N/A	N/A
Vandal Resistant, 7/8" Metal Button Single Gang Aluminum	CM-9080	N/A	PB4L-2	631AL	452	6280	N/A	N/A
Vandal Resistant, 7/8" Metal Button Narrow Aluminum	CM-9180	N/A	PB4LN-2	631 NS	452N	6280 NR	N/A	N/A
Mushroom 1 5/8", "PUSH TO EXIT", Single Gang Stainless Steel	CM-420PTE	908	N/A	623RD-EX	446E	6231	N/A	EB-1
Mushroom, 1 5/8" , Single Gang Aluminum	CM-4000	916 918	N/A	634RD-HDP	434	N/A	9450	N/A
Mushroom 1 5/8", Pneumatic Time Delay Single Gang Aluminum	CM-4085PTE	991E-PTD	N/A	623RD-EXDA	N/A	6290	N/A	TS-14
Mushroom 2 3/8", Single Gang Aluminum	CM-5000	990	PB5E	625RD-HDP	442 444	N/A	9600	N/A
Locking Mushroom, Single Gang Aluminum	CM-6000 (2 3/8")	920 (1 3/4")	N/A	N/A	432RKRU (1 1/2")	N/A	N/A	N/A
Low Profile 1" Pushbutton Single Gang Aluminum	CM-7000	N/A	N/A	N/A	N/A	N/A	9700	N/A
Econo "PUSH TO EXIT" Single Gang Stainless Steel	CM-280/7	980	PB3EN	701RD	N/A	N/A	N/A	N/A
Illuminated 2" Square Single Gang Stainless Steel	CM-30E CM-30 U/C	972	PB2	709GR-EX	422U	6270	9350	TS-2
Illuminated 2" Square Egress Single Gang Stainless Steel	CM-30EE	9721i- TD30	EEB2	N/A	423M	N/A	N/A	TS-2T
Illuminated 1/2 x 3/4" "EXIT" Single Gang Stainless Steel	CM-300RE	970	PB3	701RD-EX	N/A	N/A	9300	TS-7
Illuminated Vandal Resistant Button	CM-9600	N/A	N/A	N/A	463U	6810	N/A	N/A
Vandal Resistant Piezo Electric Push Button	CM-9700	917	N/A	N/A	N/A	N/A	N/A	N/A

Note: Specifications are subject to change without notice (April 24, 2012)
