PIVOT SETS OFFSET • INTERMEDIATE • CENTER HUNG HARDWARE
OP-7000 OFFSET PIVOT SET (KAWNEER TYPE)
- A380 Precision die cast aluminum
- Oilite bronze bushing in top frame portion
- Full race ball bearing In bottom door portions
- Door height adjustable by bottom door portion
- Case hardened stud in floor/jamb portion
- Includes steel reinforcement plates for the door portions
Top Frame Pivot Portion (includes fasteners) Kawneer P/N 50-321
Top Door Pivot Portion (includes fasteners and reinforcement plate) Kawneer P/N 50-320
Specify: Model Number and Finish
• Finishes Available:
AL - Baked Satin Aluminum PaInt
BK- Baked Black Paint
DU- Baked Storefront Bronze Paint
Bottom Door Pivot Portion (includes fasteners and reinforcement plate) Kawneer P/N 50-323
Floor/Jamb Pivot Portion (includes fasteners) Kawneer P/N 5O-325{LH) Kawneer P/N 5O-324(RH)
IP-1900 INTERMEDIATE PIVOT SET
3/4" Offset for use with Aluminum Doors and Frames
- Full race ball bearing backed by an oilite bronze bushing in the door portion
- Case hardened pin in jamb portion fully retractable for ease of installation
- Easy vertical adjustment
- Precision Aluminum die cast
- For doors up to 125lbs.
- Finishes Available:
AL- Baked Satin Aluminum Paint
BK- Baked Black Paint
DU- Baked Storefront Bronze Paint
Ordering Information IP-1901 Left IP-1902 Right
Specify: Model Number and Finish
IP-2200 INTERMEDIATE PIVOT SET
3/4" Offset for use with Aluminum Doors and Frames
- Full race ball bearing backed by an oilite bronze bushing in the door portion
- Case hardened pin in jamb portion fully retractable for ease of installation
- Easy vertical adjustment
- Precision Aluminum Extrusion
- For doors up to 125lbs.
- Finishes Available:
AL- Baked Satin Aluminum Paint
BK- Baked Black Paint
DU- Baked Storefront Bronze Paint
Specify: Model Number and Finish
International Door Closers, Inc.
COPYRIGHT 2018 INTERNATIONAL DOOR CLOSERS, INC www.intldoorclosers.com
West: 800-544-4422 • East: 800-225-6737
OFFSET PIVOT SETS 3/4" Offset for use with Aluminum Doors and Frames
- Oilite bronze bushing in top frame portion
- Case hardened, spring loaded pin in top door portion (case hardened fixed pin In Series 5000 top door portion)
- Full race ball bearing in bottom door portion
- Case hardened stud in floor/jamb portion (stainless steel stud In Series 5000 floor/jamb portion)
- 1/8" vertical adjustment
- For doors up to 125 lbs.
- Finishes Available:
- AL Baked Satin Aluminum Paint
- BK Baked Black Paint
- DU Baked Storefront Bronze Paint
Specify : Model Number and Finish
| SERIES 2000 | SERIES 3000 | SERIES 4000 | SERIES 5000 | SERIES 6000 | SERIES 7000 | ||
|---|---|---|---|---|---|---|---|
|
OP-2700
(Non-Handed) Flush Door OP-2800 (Non-Handed) 1/8" Recessed Door |
OP-3001
Left Flush Door OP-3002 Right Flush Door OP-3101 Left 1/8" Recessed Door OP-3102 Right 1/8" Recessed Door |
OP-4001
Left Flush Door OP-4002 Right Flush Door |
OP-5001
Left 1/8" Recessed Door OP-5002 Right 1/8" Recessed Door |
OP-6001
Left 7/64" Recessed Door OP-6002 Right 7/64" Recessed Door |
OP-7001
Left 1/8" Recessed Door OP-7002 Right 1/8" Recessed Door |
||
| SEE CROSSOVER REFERENCE CHART ON PAGE 148 | |||||||
|
Jackson 27
Jackson 28 Sun Valley All American Entrance Tech Rebco West |
Tubelite*
Arcadia All American Arch Aluminum Commercial Arch. Pacific Western Rebco Southwest Alum. |
US Aluminum
Sun Valley A Door MFG. Entrance Tech. |
Aldora |
Arch Aluminum
Armalite Wells Aluminum |
Kawneer | ||
* Non-Adjustable Old Type
CROSS REFERENCE CHART
JACKSON-SOMACA-CRL
| JACKSON-SOMACA-CRL PIVOT CROSSOVER REFERENCE CHART | ||||||
|---|---|---|---|---|---|---|
| APPLICATION | "OLD" JACKSON PART NO. | "OLD" SOMACA PART NO. | JACKSON CRL PART NO. | |||
| U.S. Aluminum | 41J25L628 | 3184421 | 41J25L628 | |||
| 41J25L313 | 3184421 | 41J25L313 | ||||
| 41J25R628 | 3184420 | 41J25R628 | ||||
| 41J25R313 | 3184320 | 41J25R313 | ||||
| 41J26L628 | 3184427 | 41J26L628 | ||||
| 41J26L313 | 3184327 | 41J26L313 | ||||
| 41J26R628 | 3184426 | 41J26R628 | ||||
| 41J26R313 | 3184326 | 41J26R313 | ||||
| Automatics, Besam | 41J27628 | 3184423 | OP27NHA | |||
| 41J27313 | 3184323 | OP27NHDU | ||||
| 41J28628 | 3184428 | OP28NHA | ||||
| 41J28313 | 3184328 | OP28NHDU | ||||
| Arcadia, | 41J30L628 | 3184430 | OP30LHA | |||
| 41J26L313 | 3184330 | OP30LHDU | ||||
| 41J30R628 | 3184429 | OP30RHA | ||||
| 41J30R313 | 3184329 | OP30RHDU | ||||
|
Arch Aluminum,
Tubelite, Vistawall |
41J31L628
41J31L313 41J31R628 41J31R313 |
3184432
3184332 3184431 3184331 |
OP31LHA
OP31LHDU OP31RHA OP31RHDU |
|||
| U.S. Aluminum | 41J34L628 | 3184460 | OP34LHA | |||
| 41J34L313 | 3184360 | OP34LHDU | ||||
| 41J34R628 | 3184459 | OP34RHA | ||||
| 41J34R313 | 3184359 | OP34RHDU | ||||
|
Amarlite,
Arch Aluminum, Rebco |
41J40L628
41J40L313 41J40R628 41J40R313 |
3184462
3184363 3184461 3184361 |
OP40LHA
OP40LHDU OP40RHA OP40RHDU |
|||
| Pittco, PPG | 41J41L628 | 3184442 | OP41LHA | |||
| 41J41L313 | 3184342 | OP41LHDU | ||||
| 41J41R628 | 3184441 | OP41RHA | ||||
| 41J41R313 | 3184341 | OP41RHDU | ||||
| Atlas Arch | 41J43L628 | 3184447 | 41J43L628 | |||
| 41J43L313 | 3184347 | 41J43L313 | ||||
| 41J43R628 | 3184446 | 41J43R628 | ||||
| 41J43R313 | 3184346 | 41J43R313 | ||||
| Arch Aluminum | N/A | N/A | OP50LHA | |||
| N/A | N/A | OP50LHDU | ||||
| N/A | N/A | OP50RHA | ||||
| N/A | N/A | OP50RHDU | ||||
