Pivot Configuration for 3by4 Offset Single Acting Pivots – Tech Memo

3/4" OFFSET PIVOT SET - SINGLE ACTING 0195 Pivot Set For doors up to 48" wide & weighing up to 450 lb. For up to 3 hours fire rated door-standard 0180 Top pivot 0195 Bottom Leaf into side jamb, S.S. Door Leaf S.S.(heavy duty needle bearing) Specify Handing - LH or RH 0173 Pivot Set For doors up to 36" wide & weighing up to 150 lb. For up to 3 hours fire rated door-standard 0180 Top pivot 0173 Bottom Arm into door, S.S. Floor Stud into concrete S.S.(heavy duty bearing) Specify Handing - LH or RH 0173 PIVOT SET 0195 PIVOT SET 0147 Pivot Set For doors up to 48" wide & weighing up to 600 lb. For up to 3 hours fire rated door-standard 0180 Top pivot 0147 Bottom Arm into door 2 Floor Bearing, S.S.(heavy duty) 019 Intermediate pivot (optional) Specify Handing - LH or RH L0147 Pivot Set For 1-3/4" lead-lined doors up to 48" wide & weighing up to 1000 lb. For up to 3 hours fire rated door-standard L0180 Top pivot L0147 Bottom Arm Floor Bearing, S.S.(heavy duty) 4 L019 Intermediate pivot (optional) Specify Handing - LH or RH 0147 PIVOT SET L0147 PIVOT SET

3/4" OFFSET PIVOT CONFIGURATION.DWG

PIVOT CONFIGURATION 0147,0195,0173 - 3/4" OFFSET
