PD18-M Series

• Retrofits the Adams Rite 8800 & 8600 series exit devices
• EASY INSTALL UTILIZE EXISTING HARDWARE WITH NO ADDITIONAL PREP REQUIRED
• Motor latch pullback electrication w/ PUSH TO SET - EASY ELECTRONIC ADJUSTMENT
• Long wire runs w/ 18ga No need for SPECIALITY POWER SUPLLY RIGHT ABOVE THE DOOR.

The Command Access PD18-M series is a motorized latch pullback Grade 1 architectural exit device; made for use in all institutions and commercial buildings storefront applications. All PD18-M models are equipped with our PTS "push to set" technology. We know that door conditions change and in retrofit scenarios you never know exactly what you're walking into. But with our PTS adjustment your post installation adjustment is greatly simplified in 5 quick seconds. As a retrofit for the Adams Rite 88 or 86 models are designed to utilize the existing mounting locations and mortise or rod & case assemblies without having to remove the door Install this device with the confidence of knowing that the PD18-M series meets or exceeds the high standards of other grade 1 products and carries our 3-year "no hassle" warranty, meaning we will support you.

Models Available - See PD19 series for mechanical devices

PD18-M-RIM - Complete RIM device, Non-Handed, Motorized Latch Pullback, w/electric FAIL SECURE (EU) dogging. Equal to Adams Rite 88, Specify Alum or Duro Finish

PD18-M-CVR - Complete CVR device, Non-Handed, Motorized Latch Pullback, w/electric FAIL SECURE (EU) dogging. Equal to Adams Rite 86, Specify Alum or Duro Finish

- Available in 48" with an upcharge.

U.S. Customer Support 1-888-622-2377

Visit our website for more details www.CommandAccess.com

Canada Customer Support 1-855-823-3002

Exit Devices

FEATURES:

• Our motorized latch retraction is fast, quiet, and smooth!
• MM4 Smart Module: On board diagnostics with audible feedback for adjustment and power issues
• "PTS": 5 second electronic adjustment for easy post installation adjustment
• Electric dogging rated for continuous duty Auto re-engage if pulled from the dogged position
• Low current draw: Compatible with most 24VDC, 1A (or greater) regulated & linear power supplies
• Up to 300' with 2-18ga --Long wire runs with provides installer with convenience of placing the locking device power supply in a centralized location; i.e. the same closet as the access panel
• 8' cable with Quick Connect for MM4 module to easily connect to power supply lead
• The slim, compact attractive low profile design enables mounting on narrow-style doors.
• Retrofits Adams Rite 8800/8600 series
• Maintains factory dogging
• 3-year "no hassle" warranty Longer than the traditional 1 year warranty because our stuff works!

SPECIFICATIONS:

• Voltage range 24 to 28 VDC
• System protec on unit shutdown when voltage exceeds 28VDC
• Standard Average Current Peak: 900MA, Average Current Hold: 190mA
• High Torque Average Current Peak: 1.4A,

Average Current Hold: 250mA

• PTS adjustment approx. 1/4"Electronic travel adjustment approx. 1/4"
• 300' with 18ga wire 500' with 16ga wire

ACCESSORIES: Additional charge

• Request to Exit (REX) Switch available factory installed
• Request to Exit Motor Kit ( PD18REXKIT-M) Switch available for installation in the field on motorized devices
• QC Connectors: Molex door cords with quick connectors for plug and play installation

HARDWARE

Handing

• Device is non-handed.

Pushbar Length

Standard sizes: dimensioned for 36" and 48" openings. 48" - Cutdown 0"

48" - Cutdown 0 36"- Cutdown 0"

Door Thickness

• Suits 1-3/4" standard

Projection

• 2-5/8" when fully projected, 1-5/8" when dogged.

Stile Width

• Minimum 2" Stile. Fits narrow, medium, and wide stile aluminum doors.

Dogging

• Standard dogging with hex key or cylinder dogging option. Electric dogging also available.

Fasteners

• Standard self-tapping screws

Verticle Rods

• Top and bottom steel rods for easy adjustment
• Standard device is adjustable for nominal door heights.

RECOMMEND POWER SUPPLIES:

All Command Access exit devices & field installable kits have been thoroughly cycle tested with Command Access power supplies at our factory.

For more information click here or go to our website

Model No.	Notes:
Customer:	Job No./Name:	Date:	Provided by:
