18424 Highway 99 Lynnwood, WA 98037 Phone 206-362-3290, Fax 206-362-3569 Toll free 800-525-0954 www.olympus-lock.com

IC Core: Small Format

for Best, Arrow, Falcon, KSP or equivalent interchangeable cores

6 PIN - 4,000 key changes available with master key system 7 PIN - 16,000 key changes available with master key system

OLYMPUS CAM LOCK Olympus 720 Series

Cabinet locks: Provide Olympus 720 Series (cam lock) such as manufactured by Olympus Lock, Inc. Lock to accept 6 or 7 pin small format interchangeable core cylinders such as supplied by Best, Arrow, Falcon, KSP or equivalent. Cam locks to be reversible between lost motion and key retaining and include disassembly/reassembly features to facilitate on-the-job maintenance.

OLYMPUS DEADBOLT LOCK

Olympus 721DR (door) / Olympus 721DW (drawer)

Cabinet locks: Provide Olympus 721DR (door) and Olympus 721DW (drawer) such as manufactured by Olympus Lock, Inc. Locks to accept 6 or 7 pin small format interchangeable core cylinders such as supplied by Best, Arrow, Falcon, KSP or equivalent. All locks to be field reversible and to provide dedicated door and drawer functions in order to maintain keyway verticality when installed. Include strikes and spacers as required for flush fit with outside face of casework material. Locks will provide disassembly/reassembly features to facilitate on-the-job maintenance.

OLYMPUS SLIDING DOOR LOCK

Olympus 722S (standard mount) - 722S-TBM (through-bolt mount)

Cabinet locks: Provide Olympus 722 Series sliding door lock such as manufactured by Olympus Lock, Inc. Lock to accept 6 or 7 pin small format interchangeable core cylinders such as supplied by Best, Arrow, Falcon, KSP or equivalent.

OLYMPUS DEADBOLT LOCKS

Olympus 725RD Series / Olympus 725MD Series

Cabinet locks: Provide Olympus 725 Series deadbolt door and drawer locks such as manufactured by Olympus Lock, Inc. Locks to accept 6 or 7 pin small format interchangeable core cylinders such as supplied by Best, Arrow, Falcon, KSP or equivalent. Locks will provide dedicated door and drawer functions in order to maintain keyway verticality when installed. Include strikes as required.

OLYMPUS LATCH LOCKS

Olympus 725RL Series / Olympus 725ML Series

Cabinet locks: Provide Olympus 725 Series door and drawer latch locks such as manufactured by Olympus Lock, Inc. Locks to accept 6 or 7 pin small format interchangeable core cylinders such as supplied by Best, Arrow, Falcon, KSP or equivalent. Locks will provide dedicated door and drawer functions in order to maintain keyway verticality when installed. Include strikes a required.

OLYMPUS MAILBOX LOCKS Olympus 728MBL

Cabinet locks: Provide Olympus 728MBL mailbox locks such as manufactured by Olympus Lock, Inc. Locks to accept 6 or 7 pin small format interchangeable core cylinders such as supplied by Best, Arrow, Falcon, KSP or equivalent.

18424 Highway 99 Lynnwood, WA 98037 Phone 206-362-3290, Fax 206-362-3569 Toll free 800-525-0954 www.olympus-lock.com

OLYMPUS SHOWCASE RATCHET LOCK Olympus 729R

Cabinet locks: Provide Olympus 729R sliding door ratchet lock such as manufactured by Olympus Lock, Inc. Locks to accept 6 or 7 pin small format interchangeable core cylinders such as supplied by Best, Arrow, Falcon, KSP or equivalent.

OLYMPUS LATCH LOCK Olympus L72V

Cabinet locks: Provide L72V (drawer latch lock) such as manufactured by Olympus Lock, Inc. All locks to accept 6 or 7 pin small format interchangeable core cylinders such as supplied by Best, Arrow, Falcon, KSP or equivalent. Locks will include spacers as required for flush fit with outside face of casework material

OLYMPUS LATCH LOCK (DEAD LATCH) Olympus 950IC (drawer)

Cabinet locks: Provide Olympus 950IC (drawer) locks. All drawer latch locks to provide a deadlocking function, strikes and spacers as required for flush fit with outside face of casework material. Locks to accept 6 or 7 pin small format interchangeable core cylinders such as supplied by Best, Arrow, Falcon, KSP or equivalent.

GENERAL SPECIFICATIONS

All lock bodies to accept 6 or 7 pin interchangeable core cylinders as supplied by Best, Arrow, Falcon, KSP or other equivalents. All deadbolt or latch locks to be non-handed and/or field reversible. All deadbolt and latch locks to provide dedicated door and drawer functions in order to maintain keyway verticality when installed. All cam locks to be reversible between lost motion or key retaining. All locks to be manufactured with disassembly/reassembly features to facilitate on-the-job maintenance such as provided by Olympus Lock, Inc.
