BROCHURE

DOOR CLOSERS

ASSA ABLOY

Experience a safer and more open world

2800ST

Ideal for applications where both security and accessibility are a priority.

FEATURES

• Cast aluminum body
• Adjustable spring size 1 through 6
• · Door weight: 250 lbs.
• · Unique spline arm
• · Push and pull side installation, door or frame mounted
• 30-year limited warranty

7500

Declare.

A robust, multi-sized surface closer designed to deliver superior performance and long-term reliability.

FEATURES

• · Cast aluminum closer body
• Adjustable spring sizes 1-6
• Heavy-duty arms: Regular Rigid,
• Parallel Rigid, CloserPlus®, CloserPlus Spring™ and Unitrol®
• · Slide Tracks: push or pull side mounting
• · Corrosion resistant model available (specify 7500SS)
• 25+ million cycles
• · 30-year limited warranty

9500

Multi-size cast iron door closer for high-use applications.

FEATURES

• · Cast iron closer body
• · Adjustable spring sizes 1-6
• · Heavy-duty arms available: Regular Rigid, Parallel Rigid,
• CloserPlus®, Parallel Rigid Offset and Unitrol®
• · Slide Track: push or pull side mounting
• · Closer mounting plate for easy installation
• · 25+ million cycles
• · 30-year limited warranty

8000

Multi-sized surface closer with a complete range of arms and a sleek, minimal design suited for architectural openings.

FEATURES

• Cast aluminum closer body
• · Adjustable spring sizes 1-6
• · Heavy-duty arms available: Parallel
• · Rigid, CloserPlus®, CloserPlus Spring™ and Unitrol®
• · Available with full or slim line cover
• 25+ million cycles
• · 30-year limited warranty

1600

Fully adjustable door closer for aluminum storefronts and other medium traffic applications.

FEATURES

• Cast aluminum closer body
• Adjustable sizes (1-6) and fixed sizes (3 or 4) available
• Heavy-duty arms available: Parallel Rigid, CloserPlus®, CloserPlus Spring™, Cushion Stop and Unitrol®
• · Corrosion resistant model available (specify 1601SS)
• 25+ million cycles
• · 30-year limited warranty

78-B/F

Potbelly closer ideal for retro look.

FEATURES

• Cast aluminum closer body
• Adjustable spring power:
  • B/D Spring size 2, 3, or 4
  • E/F Spring size 5 and 6
• · 10-year limited warranty

Experience a safer and more open world

1700

Multi-feature closers with compact design, ideal for application on interior doors.

FEATURES

• · Cast aluminum closer body
• Size 3 or 4 depending on installation
• · Installs regular arm, parallel arm or top jamb
• 5-year limited warranty

410

Attractive retrofit solution for moderate-to-high traffic applications.

FEATURES

• · Cast iron closer body
• · Adjustable spring sizes 1-6
• Optional arms: Heavy-duty arm with removable stop, heavy-duty arm with removable stop and spring buffer
• Direct replacement for LCN 4040XP
• · 10-year limited warranty

210

Adjustable door closer for light duty commercial applications.

FEATURES

• · Cast aluminum closer body
• Adjustable spring sizes 1-6
• · Full plastic cover
• Optional heavy-duty arm with removable stop
• 10-year limited warranty

160

Simple door control for light duty applications.

FEATURES

• · Cast aluminum closer body
• · Adjustable sizes (1-4) and fixed size (4) available
• · Hold open arms available for 161BF only
• 5-year limited warranty

NORTON RIXSON CLOSERS COMPARISON

	CAST IRON
CERTIFICATION & WARRANTY	9500	410
ANSI/BHMA A156.4	Grade 1	Grade 1
UL & ULC Listed	Yes	Yes
Warranty	30 Year	10 Year
Extended Cycle Testing	25 Million	Per Standard
End of Life Recycling Program Available	Yes	Yes
SIZE & CONSTRUCTION
Construction (Body)	Cast Iron	Cast Iron
Mounting Hole Pattern	1" × 10"	2-1/4" x 5"*
Spring Size	Adjustable 1-6	Adjustable 1-6
Closer Body (Handing)	Non-Handed	Non-Handed
Standard Backcheck	Yes	Yes
OPTIONS
Plastic Cover	Standard	Standard
Metal Cover Option	Optional	No
Slim Line Cover Option	No	No
Delayed Action Option	Yes	Yes
Sex Nuts & Bolts (Tri-Style® pack)	Optional	Standard
Finishes	Multiple	689, 690 only
APPLICATION / ARM TYPE AVAILABIL	LITY
Regular	•	•
Top Jamb	•	•
Parallel	•	•
Regular Rigid	•
Parallel Rigid	•
Heavy Duty: HDH/HDN		0
CloserPlus	•
CloserPlus Spring		0
CloserPlus Ramp
Cushion Stop
Unitrol	•
Low Profile
Slide Track	•

NORTON RIXSON CLOSERS COMPARISON ALUMINUM 2800ST 7500 8000 1600 1700BC 78B/F 210 160 Grade 1 Grade 1 Grade 1 Grade 1 Grade 3 Grade 3 Grade 1 Grade 1 Yes Yes Yes Yes Yes Yes Yes Yes 30 Year 30 Year 30 Year 30 Year 5 Year 10 Year 10 Year 5 Year N/A 25 Million 25 Million 25 Million Per Standard Per Standard Per Standard Per Standard Yes Yes Yes Yes Yes Yes Ves Yes Aluminum Aluminum Aluminum Aluminum Aluminum Aluminum Aluminum Aluminum 1"x 11-1/8" 2-3/8" x 6-3/4" 3/4" x 12" 3/4" x 9-1/16" 3/4" x 8" 4-1/8" x 1-3/8" 3/4" x 12" 3/4" x 9-1/16" Size 3 or 4 Adjustable 1-6 Size 2-4; Adjustable 1-4 Adjustable 1-6 Adjustable 1-6 Adjustable 1-6 (depends on Adjustable 1-6 Size 3, 4 Size 5 or 6 Size 4 installation) Non-Handed Non-Handed Non-Handed Non-Handed Non-Handed Non-Handed Non-Handed Handed Yes Yes Standard Standard Standard Optional Optional Standard Optional No No Optional Optional No No No No Nο Optional No No No No No No No No Yes Yes No No Yes No No Standard Standard Optional Optional Optional Optional Optional Optional Multiple Multiple Multiple Multiple 689, 690 Multiple 689, 690, BSP 689, 690, BSP • • • • • • • • • • • • • • • • • • • • • •

The ASSA ABLOY Group is the global leader in access solutions. Every day, we help billions of people experience a more open world.

ASSA ABLOY Opening Solutions leads the development within door openings and products for access solutions in homes, businesses and institutions. Our offering includes doors, frames door and window hardware, mechanical and smart locks, access control and service.

	ARCH	HITECTURAL	COMMERCIAL
NORTON RIXSON	LCN	DORMAKABA	Best	FALCON	DESIGN HARDWARE	HAGER	PDQ	CAL ROYAL
2800ST		T93
7500	4040XP	8900	EHD9000
9500
8000	1460	8600	HD7000
1600	1260	7400
78B/F
410		QDC100			416	5100	7100	DR441
210	1450	QDC200		SC80A	314	5200	5500	CR801
160	1250	QDC300		SC60A	116	5300	3100	500

Note: No products are exactly alike. This cross reference represents our judgement of products that are most similar. Information has been obtained from trade sources. It is not represented nor guaranteed that any product exactly equals any other products.

PATENTS

www.assaabloydss.com/patents

Since 1880, Norton Rixson door controls have been an integral part of schools, hospitals and businesses around the globe. When you need products and people that perform at the highest level, rely on Norton Rixson – From Open to Close.
