Norton Rixson 7500 Series Door Closer,P7500,P7700,Parallel Arm,Non-Hold Open,with 2018 Soffit Plate,with or with…_7377-0203

3 holes for soffit plate

23/32 (18.3)

4-3/4

(120.7)

6 - 3/4

(171.5)

4 holes for 7788 drop-plate

4 holes for closer

7/8 (22.2) 23/32 (18.3) 4 (101.6) 2-7/8* (73) 1/4 (6) 2-3/8 (60.3)

(51)

minimum

(102)

1-3/8 * 12-3/4 (35)(323.9) 5/16 (7.9)Preparation for Fasteners Door or Fasteners Drill-Sizes Frame #14 type "A" Wood 3/16" (4,30mm.) S.M. screw Standard Arm: 1-1/4" (32mm.) Closer: 2-3/4" 7/32" (5.50mm.) Aluminum (70mm.) drill: #7 (.201" dia.)

Metal

Hollow-

Aluminum

or Wood

AII

Metal

%-20 machine-screw

Sex-nuts and bolts

Through-bolts and

grommet-nuts

Optional

Do not scale drawing Left hand door shown Dimensions are in inches (mm.)

Caution: Door swing may be limited by door, frame, wall, or hardware conditions.

Measure from soffit-plate mounting surface. 2018 soffit-plate may be applied onto frame-rabbet when frame-stop-height does not exceed 5/8" (16mm.).

Hollow-metal doors require channel or box-type reinforcement when thru-bolt mount is specified.

Hinge

Pivot

Sex-bolts required for wood or plastic faced fire-door mounting.

Minimum thickness recommended for reinforcements in hollow-metal doors and frames: .1046" (2.66mm.) unless otherwise noted.

P7500 and P7700 Series Door Closers With 2018 Soffit Plate With or Without 7788 Drop Plate Parallel Arm Installation With Non-Hold Open Arm

RIXSON

tap: 1/4-20

to closer

9/32" (7.00mm.) through;

3/8" (9.50mm.) on door or

transom-face opposite

3/8" (9.50mm.) through

9/32" (7.00mm.) through:

3/8" (9.50mm.) dia-x

3/8" (10mm.) deep on

door or transom-face

opposite to closer

ASSA ABLOY

TEMPLATE NUMBER

7377-0203 3

12/21
