Marks USA i-Qwik Line – IQLite,IQData, IQProx Spec Sheet
Open the original PDF document
View PDF
INSTALLATION
- CABLEGARD™ PROTECTS WIRES FOR EASY INSTALLATION
- STANDARD ANSI DOOR PREP WITH ONE ADDITIONAL HOLE
- CYLINDRICAL, MORTISE & RIM EXIT DEVICE INTERFACE MODELS AVAILABLE
Distributed By:
IQLITE Standard Features
- CableGardTM protects wires for easy installation
- Standard ANSI door prep with one additional hole
- Pre-programmed code
- Keypad programmable
- 160 User codes
- Temporary user codes
- Passage mode
- Pin only mode
- Double code entry for maximum security
- Two wire remote release
- 16 Digit tactile metal keypad
- Durable black powder coat finish w/26D American levers
- Weatherproof standard
- Audible & visible entry indicator
- Audible low battery alert
- 4 "AA" batteries; 100,000 operations
- Easy installation
- Lifetime Mechanical Warranty;
- 2 Year Electronic Warranty Finishes are excluded from this warranty
IQDATA Standard Features
- CableGardTM protects wires for easy installation
- Weatherproof standard
- Shielded electronics
- 16 Digit tactile metal keypad
- 320 User capability
- 1600 Event audit trail ( Audit trail requires i-Dat module)
- 160 Scheduled events
- 32 Programmable holidays
- Real time clock
- Multiple entry codes for max security
- Full scheduling features
- Pin only
- Terminator on/off
- Built in relay
- 3-10 Digit user code
- Temporary user codes
- First manager to arrive
- Panic alarm interface
- Two wire remote release
- Fire tower lock function
- Programmable by keypad or by use of the i-Dat software package
- On-the-door upgradeable memory
- Privacy mode (input to lockout keypad entry)
- Scheduled/Manual passage mode
- Audible & visible entry indicator
- Audible low battery alert
- 4 "AA" batteries included
- Lifetime Mechanical Warranty
- 2 Year Electronic Warranty; Finishes are excluded from this warranty
IQPROX Standard Features
- Weatherproof standard
- 16 Digit tactile metal keypad
- 3008 User capability
- 1180 Event audit trail
- 1600 Scheduled events
- 56 Programmable holidays
- Real time clock
- Multiple entry codes for max security
- Full scheduling features
- Pin only
- Terminator on/off
- Built in relay
- 3-10 Digit user code
- Temporary user codes
- First manager to arrive
- Panic alarm interface
- Fire tower lock function
- Accepts HID cards and fobs in 26, 33 and 37 format
- Programmable by keypad or by use of the i-Dat software package
- Privacy mode (input to lockout keypad entry)
- Scheduled/Manual passage mode
- Audible & visible entry indicator
- Audible low battery alert
- 4 "AA" batteries included
- HI-SECURITY™ Cylinder Standard on Cylindrical Model
- Lifetime Mechanical Warranty
- 2 Year Electronic Warranty; Finishes are excluded from this warranty
