COMMAND ACCESS

ELECTRIFIED LATCH RETRACTION

MLRK1-MRK8

MARKS M8800 SERIES

  • · "PTS" Push to set technology
  • Easy installation underneath the push pad for ultimate cutdown
  • FAST, QUIET, SMOOTH
  • True Electronic Dogging Full push pad retraction
  • UL LISTED

The MLRK1-MRK8 is a practical and cost-effective way to convert mechanical Marks M8800 series device to an electrified latch pullback device while maintaining the UL listing. Our redesigned kit is even easier to install & improves the latch retraction pulling power. It is equipped with PTS technology allowing for an easy post-installation adjustment of the latch/latches.

SPECIFICATIONS

Voltage:

  • Voltage range 24V +/- 10%
  • System protection unit shutdown when voltage exceeds 28VDC
  • Average Current Peak: 900A
  • Average Current Hold: 215mA
  • PTS adjustment approx. 1/4"

Wire Run:

300' with 18ga wire

Product Details:

Weight: 2 Lbs

Device Cutdown Details:

36" & 48" - Minimum 8.75" of Filler Plate

Accessories

MRK8REXKIT-M-ED - Built-in or Field Installable REX kit

FEATURES

  • MM4S Smart Module: On board diagnostics with audible feedback for adjustment and power issues
  • "PTS": 5 second electronic adjustment for easy post installation adjustment
  • Electric dogging rated for continuous duty
    • Auto re-engage if push pad is pulled from dogged position
  • Low Current Draw Field switchable to "High Torque" mode
  • Up to 300' wire run with 2-18ga wire -Long wire runs provides installer with convenience of placing the Command locking hardware power supply in a centralized location: i.e. the same closet as the access control panel
  • 6" robust Molex Pigtail + 6' Power lead to easily connect to power supply lead
  • Request-to-exit kit available
  • 3-year "no hassle" warranty

How to Order

PART # EASY ORDER # DESCRIPTION
MLRK1-MRK8 72717 Kit for Marks M8800 Series. EU 24V
MLRK1-MRK8 REX 72718 Kit for Marks M8800 Series. EU 24V w/ REX
SMOOTE

MLRK1-MRK8 MATRIX

Our kit will work in new installations and as a replacement for installations with existing electrifications, matrix lists available options.

Marks Kit Mechanical CAT Modified CAT Modified Marks SDC Motor ACSI Motor
Device Solenoid Motor Motor (LR100-) (1550K-)
MRK8 \checkmark - \ - -

NEED A LOCKING HARDWARE POWER SUPPLY?

RECOMMENDED LOCKING HARDWARE POWER SUPPLIES:

  • PS220/220B
    • PS210 PS440B

PS204/PS204B •

PS480B
