Electrified Latch Retraction

MLRK1-FAL17

Falcon 16/17 & First Choice 36/37 series

• 1 Touch "PTS" Push to set technology
• Easy installation Fast, quiet, smooth
• True Electronic Dogging Full push pad retraction
• UL Listed
• 3 year warranty

The MLRK1-FAL17 is a robust, straightforward field-installable motorized latch retraction kit for Falcon Dor-o-Matic 1690/1790 & First Choice 3600/3700 series exit devices. It utilizes a CAT-designed custom assembly to maximize the pulling force. The only hole you'll need to drill is the raceway! It uses our new 1 TOUCH PTS "Push to Set" technology, making post-installation adjustments a breeze.

SPECIFICATIONS

Voltage:

• Voltage range 24VDC +/- 10%
• System protection unit shutdown when voltage exceeds 28VDC
• Standard Average Current Peak: 900mA, Average Current Hold: 200mA
• PTS adjustment approx. 1/4"

Wire Run:

• 300' with 18ga wire

Built-in REX:

• SPDT rated at .5A @ 24V
• Green (C)
• Blue (NO)
• Gray (NC)

Product Details:

• Weight: 2 Lbs

Device Cutdown Details:

• 36" 1-1/4"
• 48" 1-1/4"

*For other sizes: See complete PD10 devices, which can be relocated to match specific cutdown sizes.

FEATURES

• Next Generation MM5 Smart Module: On board diagnostics with audible feedback for adjustment and power issues
• 1 Touch "PTS": Quick & easy post-installation adjustment
• Electric dogging rated for continuous duty Auto re-engage if push pad is pulled from dogged position
• Low Torque Mode: Now capable of pulling all devices, even tall vertical rod doors!
• Up to 300' wire run with 2-18ga wire Long wire runs provides installer with convenience of placing the Command locking hardware power supply in a centralized location; i.e. the same closet as the access control panel
• 6''cable with Robust Quick Molex Connect for MM5 module to 6' Power Lead to easily connect to Power Supply.
• 3-year "No Hassle" Warranty

How to Order

PART #	EASY ORDER #	DESCRIPTION

MLRK1-FAL17 72685	Kit for Falcon 16/17 & First Choice 36/37 SERIES. EU 24V w/REX

MLRK1-FAL17 Matrix

The MLRK1-FAL17 will work in new installations and as a replacement for installations with existing electrifications, matrix lists available options.

Kit Falcon	Mechanical Device	fied d oi odi Solen M AT C	fied otor odi M M AT C	N d oi O Solen C AL F	K) otor A 00-F M C R1 D S (L	otor A) M N/ SI ( C A
FAL17						_

Need ^a locking hardware power supply?

Recommended Locking Hardware Power Supplies:

• PS204/PS204B
• PS220/220B
• PS480B

• PS210
• PS440B
