OPERATING AND PROGRAMMING INSTRUCTIONS Gemini Electronic: GE 370
| М | ODE | |||||
|---|---|---|---|---|---|---|
| FUNCTION | PUBLIC | PRIVATE | KEY SEQUENCE | NOTES | ||
| MASTER CO | ODF FI | INCT | IONS - for stens 1-3 n | lease | enter the relevant numbe | ers in the sequence shown below |
| WASTER CO | JULI | o i a c i | STEP 1 | I the sequence shown below | ||
| CHANGE MASTER CODE | · / | ✓ | [l#] [Old Master Code] | 01 | MASTER CODE IS FIGUE DIGITS | |
| CHANGE USER CODE | · · | [#] [Master Code] | 01 | [New Master Code] [New Master Code] [New User Code] | MASTER CODE IS EIGHT DIGITS USER CODE IS FOUR DIGITS | |
| DELETE USER CODE | 1 | · · | [Master Code] | 02 | [ivew oser code] | OPENS LOCK AND DELETES USER CODE |
| SET / CHANGE SUB-MASTER CODE | 1 | 1 | [#] [Master Code] | 03 | [New Sub-Master Code] | SUB-MASTER CODE IS SIX DIGITS |
| DELETE SUB-MASTER CODE | · / | · · | [#] [Master Code] | 07 | [New Sub-Master Code] | DELETES SUB-MASTER CODE |
| OPEN LOCK | 1 | 1 | [Master Code] | 07 | DELETES USER CODE IN PUBLIC MODE | |
| CLOSE LOCK | AUTO | [master code] | RE-LOCKS AUTOMATICALLY AFTER 4 SECONDS | |||
| SET PUBLIC MODE | √ √ | [#] [Master Code] | 08 | DELETES ALL EXISTING USER CODES | ||
| SET PRIVATE MODE | 1 | [#] [Master Code] | 09 | [New User Code] | DELETES ALL EXISTING USER CODES | |
| SET TECHNICIAN MODE | · / | [#] [Master Code] | 10 | [New Technician Code] | TECHNICIAN CODE IS SIX DIGITS | |
| REMOVE TECHNICIAN MODE | 1 | [#] [Master Code] | 11 | [New recrimetari code] | DELETES TECHNICIAN CODE | |
| SET AUTO-TIMED UNLOCK ON & SET TIME | 1 | [#] [Master Code] | 16 | [Time Code] | SEE NOTES ON TIMERS BELOW | |
| SET AUTO-TIMED UNLOCK OFF | 1 | [#] [Master Code] | 17 | [mine code] | UNIT WILL NOT OPEN AUTOMATICALLY | |
| SET AUTO-TIMED CODE CANCEL ON & SET TIME | 1 | [#] [Master Code] | 26 | [Time Code] | DISABLES USER CODE AFTER SET TIME - SEE NOTES ON TIMERS | |
| SET AUTO-TIMED CODE CANCEL OFF | 1 | [#] [Master Code] | 27 | [mine code] | UNIT WILL NO LONGER CANCEL USER CODE | |
| CODE | FILE | o ontou the velouent num | ||||
| CODE | • | bers in the sequence shown below | ||||
| CHANGE USER CODE | √ | [#] [Sub-Master Code] | 02 | [New User Code] | USER CODE IS FOUR DIGITS | |
| CHANGE SUB MASTER CODE | V | ✓ | [#] [Sub-Master Code] | 03 | [New Sub-Master Code] | SUB-MASTER CODE IS SIX DIGITS |
| DELETE USER CODE | V | [Sub-Master Code] | OPENS LOCK AND DELETES USER CODE | |||
| OPEN LOCK | ✓ | [Sub-Master Code] | DELETES USER CODE IN PUBLIC MODE | |||
| CLOSE LOCK | AUTO | RE-LOCKS AUTOMATICALLY AFTER 4 SECONDS | ||||
| USER CO | DE FUI | NCTI | ONS - for steps 1-3 ple | ase er | nter the relevant numbers | s in the sequence shown below |
| CHANGE USER CODE | ✓ | [#] [Old User Code] | 02 | [New User Code] [New User Code] | USER CODE IS FOUR DIGITS | |
| OPEN LOCK | ✓ | ✓ | [User Code] | |||
| CLOSE LOCK | ✓ | [User Code] | WHEN SINGLE USER CODE ENTRY MODE IS SET | |||
| CLOSE LOCK | ✓ | [User Code] [User Code] | WHEN DOUBLE USER CODE ENTRY MODE IS SET | |||
| CLOSE LOCK | AUTO | RE-LOCKS AUTOMATICALLY AFTER 4 SECONDS | ||||
| TECHNI | CIAN ( | CODE FUNCTIONS | ||||
| OPEN LOCK | / | [Technician Code] | DOES NOT DELETE USER CODE | |||
| CLOSE LOCK | AUTO | RE-LOCKS AUTOMATICALLY AFTER 4 SECONDS | ||||
| FUNCTIONS | ς Δ\/ΔΙ | LABLE TO ALL CODES | ||||
| BATTERY CHECK | 1 | √ | [#] [#] | LABEL TO ALL CODES | REPLACE BATTERIES IF RED LIGHT SHOWS | |
| • | DE EXAMPLES | |||||
| NOTES | TIMER FUNCTIONS - | BATTERY CONDITION INDICATOR | ||||
|
ALL ACCEPTABLE BUTTON PRESSES ARE SIGNIFIED
BY A GREEN LIGHT. |
TIME CODE | 001 | 1 MIN | GREEN LIGHT - EXCELLENT | ||
| INCOMPLETE FUNCTIONS "TIME-OUT" AFTER 4 SECONDS. | TIME CODE | 010 | 10 MINS | AMBER LIGHT - GOOD | ||
| TIME CODE | 030 | 1/2 HR | RED LIGHT - LOW | |||
| ERRORS AND "TIME-OUTS" ARE SIGNIFIED BY FLASHING | TIME CODE | 060 | 1 HR | |||
| TIME CODE | 480 | 8 HRS | RED LIGHT - CHANGE BATTERIES AS SOON AS POSSIBLE | |||
| RED LIGHT. | TIME CODE | 720 | 12 HRS | |||
|
FOLLOWING AN ERROR OR "TIME-OUT", UNIT REVERTS TO
PREVIOUS SETTINGS. |
TIME CODE | 999 | 16 HRS 39 MINS ( MAXIMUM ) |
FLASHING RED LIGHT PRIOR TO LOCK OR UNLOCK INDICATES LOW
BATTERY VOLTAGE CHANGE BATTERIES AS SOON AS POSSIBLE |
||
|
TIME CODES ARE 3-DIGIT CODES CORRESPONDING
TO THE NUMBER OF MINUTES. |
ALL TIMES ARE APPROXIMATE +/- 5% | |||||
| MASTER CODE (8 digits | SUB MASTER CODE (6 digits) (No Default) | USER CODE (4 DIGITS) | ||||
| MASTER CODE (8 digit: | :) | SUR_MAST | ER COL | DE (6 digits) (No Default) | USER CODE (4 digits) | |
| WASTER CODE (8 digits |
.,
| | |
] | | | T (O digits) (NO Delault) | OSER CODE (4 digits) | ||
| II . | II . | | | | | ||||
| III . | II | 1 11 | ||||
LockeyUSA 4245 S. Lincoln Rd. Mt. Pleasant, MI 48858
T: 888.395.0163 E: info@lockeyusa.com W: www.lockeyusa.com
