OPERATING AND PROGRAMMING INSTRUCTIONS for EC-783 & EC-785 RFID Lock
| MODE | ||||||
|---|---|---|---|---|---|---|
| FUNCTION | PUBLIC | PRIVATE | KEY SEQUENCE | NOTES | ||
| MASTER CODE FUNCTIONS - FOR | STEPS | 5 1-3 P | LEASE ENTER THE REL | EVANT NUM | BERS IN THE SEQUENCE SHOW BE | ELOW (EG. STEP1STEP2STEP3) |
| STEP 1 | STEP 2 | STEP 3 | ||||
| ADD MASTER CARD | ✓ | ✓ |
[logo] [logo] [Old Master
CARD] [press logo until] |
**** |
[Old Master CARD] [New Master CARD] (hold
new card for 5 seconds) |
|
| DELETE SINGLE MASTER CARD (with card) |
[logo][logo] [Master CARD]
[press logo until] |
**** | [Scan Master card to delete] [Master CARD] | |||
| DELETE SINGLE MASTER CARD (without card) |
[logo][logo] [Master CARD]
[press logo until] |
**** | [press logo until master light config is shown] [Master CARD] | |||
| ADD USER CARD | ✓ |
[logo][logo] [Master CARD]
[press logo until] |
**** | [Master CARD] [New USER CARD] | Record light sequence after adding for user number | |
| DELETE ALL USER CARDS | ✓ |
[logo][logo] [Master CARD]
[press logo until] |
**** | [Master CARD] [press logo unti | DELETES ALL USER CODES | |
| DELETE USER CARD | ✓ | [Master CARD] | OPENS LOCK AND DELETES USER CODE | |||
| DELETE SINGLE USER CARD(with card) | √ |
[logo][logo] [Master CARD]
[press logo until] |
**** | [Master CARD] [Scan USER card] | Deletes that user card | |
| DELETE SINGLE USER CARD (without card) | √ |
[logo][logo] [Master CARD]
[press logo until] |
**** |
[Master CARD][press logo until user light
config is shown][Master CARD] |
Deletes the user in that location | |
| OPEN LOCK | ✓ | √ | [Master CARD] | [logo] | DELETES USER CARD IN PUBLIC MODE | |
| CLOSE LOCK | AUTO | [logo] | RE-LOCKS AUTOMATICALLY AFTER 4 SECONDS | |||
| SET PUBLIC MODE | ✓ |
[logo][logo] [Master CARD]
[press logo until] |
**** | [Master CARD] | ||
| SET PRIVATE MODE | √ |
[logo][logo] [Master CARD]
[press logo until] |
**** | [Master CARD] | ||
| SET AUDIO ON | √ | ✓ |
[logo][logo] [Master CARD]
[press logo until] |
[Master CARD] | Turns AUDIO ON | |
| SET AUDIO OFF | ✓ | √ |
[logo][logo] [Master CARD]
[press logo until] |
[Master CARD] | Turns Audio OFF | |
| ECO MODE SET | ✓ | √ |
[logo][logo] [Master CARD]
[press logo until] |
**** | [Master CARD] | Default mode |
| SLOW SCAN MODE SET | ✓ | √ |
[logo][logo] [Master CARD]
[press logo until] |
**** | [Master CARD] | |
| USER CODE FUNCTIONS | - PLE | ASE EN | NTER THE RELEVANT N | IUMBERS IN | THE SEQUENCE SHOW BELOW (EG | G. STEP1STEP2STEP3) |
| OPEN LOCK | ✓ Scan USER card (Eco Mode requires logo button press before scan) | |||||
| CLOSE LOCK | √ | Scan USER card (Eco Mode re | ||||
| CLOSE LOCK | AUTO | RE-LOCKS AUTOMATICALLY AFTER 4 SECONDS | ||||
| FUNCTIONS | S AVAII ARI F | TO ALL CODES | ||||
| BATTERY CHECK | √ | √ | [logo] [logo] [logo] | I I I I I I I I I I I I I I I I I I I | REPLACE BATTERIES IF RED LIGHT SHOWS | |
| BATTERT CHECK | _ v | REPLACE BATTERIES IF RED LIGHT SHOWS | ||||
| NOTES |
MODE
FINITION |
MODE | BATTERY CONDITION INDICATOR | |||
|
ALL ACCEPTABLE BUTTON PRESSES ARE
SIGNIFIED BY A GREEN LIGHT. |
ECO | BUTTON PRESS FIRST | FOUR GREEN LIGHTS - EXCELLENT | |||
| SCAN | J. | THREE GREEN LIGHTS - VERY GOOD | ||||
| INCOMPLETE FUNCTIONS "TIME-OUT" AFTER 4 SECONDS. | TWO GREEN LIGHTS - GOOD ONE GREEN LIGHT - LOW | |||||
|
ERRORS AND "TIME-OUTS" ARE SIGNIFIED
BY FLASHING RED LIGHT. |
RED LIGHT -
CHANGE BATTERIES AS SOON AS POSSIBLE |
|||||
|
FOLLOWING AN ERROR OR "TIME-OUT",
UNIT REVERTS TO PREVIOUS SETTINGS. |
FLASHING RED LIGHT PRIOR TO LOCK OR UNLOCK INDICATES LOW BATTERY VOLTAGE | |||||
ENSURE THAT YOU KEEP A SAFE RECORD OF YOUR USER CARDS. ENSURE YOU KEEP THE MASTER CARD SAFE WITHOUT IT YOU CAN'T CHANGE ADD OR DELETE USERS
