LS Option – Less Spring – Template

OVERHEAD STOPS ONLY - LESS SPRING 2-7/16" SPRING REPLACEMENT BLOCK 1000 / 9000 SERIES (ABH-6287) 1000SL SERIES (ABH-7229) 1-3/4" SPRING REPLACEMENT BLOCK 1-7/8" SPRING REPLACEMENT BLOCK 4400 SERIES (ABH-6431) 2-13/32" SPRING REPLACEMENT BLOCK 4000 SERIES (ABH-6432) 2-1/2" SPRING REPLACEMENT BLOCK 1000RA SERIES (ABH-5364) 2-1/2" SPRING REPLACEMENT BLOCK

4000RA SERIES (ABH-7771)

THIS STOP ONLY OVERHEADS ARE TYPICALLY USED WITH SINGLE POINT ELECTRIC DOOR CLOSER ARE PROVIDED WITHOUT THE SHOCK-ABSORBING SPRING. AS AN AUXILIARY STOP, USE OF THESE MODELS MAY INCREASE THE LIFE OF THE CLOSER.

PLEASE ORDER UNITS "LESS SPRING" (SUFFIX LS )

NOTE: Care should be taken when the "LESS SPRING" model is used in other applications. Eliminating the shock-absorbing spring may put additional stress on the frame and door.

www.abhmfg.com E-mail: bhinfo@abhmfg.com Architectural Builders Hardware Mfg., Inc. 1222 Ardmore Ave., Itasca, IL 60143 630.875.9900; FAX 800.9FAXABH (932.9224)

TM-LESS SPRING OPTION-02.DWG

OVERHEAD STOP LESS SPRING FUNCTION

c 2020 ABH Mfg., Inc. printed in USA

REVISED 03-31-20 PAGE 1 OF 1
